Specifications
Laser dust particle counter(instrument for short) is used to measure size and number of dust particle per volume in clean airCharacteristics:
Y09-6 laser dust particle counter
Y09-6 laser dust particle counter(instrument for short) is used to measure size
and number of dust particle per volume in clean air, and may directly examine
clean condition of Class300,000 to Class10. This instrument adopts
semiconductor laser source. It has the characters of small volume, light weight,
high precision, simple operation, MPU control, as well as may store, print measure
results and is convenient to test clean condition.
Optional functions: remote control though professional software.
Application; It is widely used for clean examination in electron, optics, chemistry,
food, cosmetic, medicine, biological products, aviation and other departments.
parameter:
ParameterModel |
Y09-6 laser dust particle counter (LED) |
Overall dimension |
205*280*125mm3 |
Display way |
LED |
Quality |
4.5kg |
Max. power consumption |
40w |
Power supply |
AC220V±10,50HZ |
Particle passage |
0.30.50.712510µm; directly display particle consistence |
Sampling flow |
2.83L/min |
Test period |
1min2min 3min 10min |
Self-cleaning time |
≤20 min |
Built-in printer |
|
Alarm |
Class100, 1000 |
Working condition |
Temperature10oc-30o c,humidity20-70,atmospheric pressure86kPa-106kPa |
Max. allowed sampling consistence |
35000 per square meters (Dust particle size can not be more than 0.5µm), sampling air can not contain acid, alkali and other corrosive gas. |
Time of continuous working |
8h |
Light source and service life |
Semiconductor laser; service life is more than 30000 hours. |
Optional fittings |
Assistant vehicles (with chargeable power supply for six hours continuously), stainless steel small trolley, |
Fittings |
Sampling bracket, 1 sampler of constant speed, 3 volumes of dustless printing paper |
