Help CenterDD-BJ0210 10t Hydraulic Bottle Jack
Related Products
-
DD-BJ0212 12t Hydraulic Bottle JackNegotiableMOQ: 100 Pieces -
DD-BJ0216 16t Hydraulic Bottle JackNegotiableMOQ: 100 Pieces
-
DD-BJ0220 20t Hydraulic Bottle JackNegotiableMOQ: 100 Pieces
-
DD-BJ0232 32t Hydraulic Bottle JackNegotiableMOQ: 50 Pieces
-
DD-BJ0250A 50t Hydraulic Bottle JackNegotiableMOQ: 50 Pieces
Specifications
10t Hydraulic Bottle JackHigh Quality,test one by one.
Factory Price.
Good Service.
OEM is accepted.
10t Hydraulic Bottle Jack
|
CAPACITY
(TON)
|
MIN. H
(MM)
|
LIFT. H
(MM)
|
ADJU.H
(MM)
|
MAX.H
(MM)
|
PACKAGE SIZE
(CM)
|
N.W
(KG)
|
G.W
(KG)
|
QTY/CTN
(PCS)
|
QTY/20FT
(PCS).
|
|
10 |
200 |
125 |
65 |
390 |
Color Box |
56X15X25=0.021 |
5.5 |
6.0 |
4 |
3332 |
Hydraullic bottle jack is ideal for automotive,truck,farm,industrial and construction work.
A hydraulic bottle jack is an excellent device for easily and quickly lifting a haevy load but it is NOT designed for long term holding.If you plan on lifting a load and keeping it up for extended periods of time,say,overnight,you can use the Hydraulic Bottle Jack to lift,but for the holding you MUST transfer the load to a jack stand,railroad ties/cribbing,bricks,steel or other devices.
Operates in vertical or horizontal positions.Fabricated from hard cast steel with heat treated stress areas & extension screw.Machined and polished cylinders with die-cut threads.Durable baked enamel rust free finish.
Other Hydraulic Bottle Jack
MODEL |
CAPACITY
(TON)
|
MIN. H
(MM)
|
LIFT. H
(MM)
|
ADJU.H
(MM)
|
MAX.H
(MM)
|
PACKAGE SIZE
(CM)
|
N.W
(KG)
|
G.W
(KG)
|
QTY/CTN
(PCS)
|
|
| DD-BJ0202 | 2 | 148 | 80 | 55 | 283 | Color Box | 60x21x20=0.0252 | 2.2 | 2.4 | 10 |
| Blow Case | 35x35x29=0.0356 | 2.2 | 2.7 | 6 | ||||||
|
DD-BJ0204 |
4 | 178 |
110 | 55 | 343 | Color Box | 61x14x22=0.0188 | 3.0 | 3.4 | 5 |
Blow Case |
39x36x30=0.0422 |
3.0 |
3.6 |
6 |
||||||
|
DD-BJ0206 |
6 | 181 | 110 | 60 | 351 | Color Box | 61x14x22=0.0188 | 4.1 | 4.4 | 5 |
| Blow Case | 41x26x33=0.0352 | 4.1 | 4.6 | 4 | ||||||
| DD-BJ0208 | 8 | 200 | 125 | 65 | 390 | Color Box | 52x14x24=0.0178 | 5.0 | 5.4 | 4 |
|
DD-BJ0210 |
10 | 200 |
125 | 65 | 390 | Color Box | 56x15x25=0.021 | 5.5 | 6.0 | 4 |
| DD-BJ0212 | 12 | 217 | 125 | 65 | 407 | Color Box | 30x16x26=0.0125 | 6.8 | 7.2 | 2 |
| DD-BJ0216 | 16 | 227 | 145 | 60 | 432 | Color Box | 32x17x26=0.0142 | 7.8 | 8.2 | 2 |
| DD-BJ0220 | 20 | 235 | 145 | 60 | 440 | Color Box | 37x18x27=0.018 | 10 | 10.5 | 2 |
| DD-BJ0232 | 32 | 250 | 150 | 0 | 400 | Color Box | 37x19x27=0.019 | 14 | 14.5 | 2 |
| DD-BJ0250A | 50 | 265 | 155 | 0 | 420 | Carton | 20.5x20x28=0.0115 | 19 | 20 | 1 |
DD-BJ0250B |
50 |
300 |
180 |
0 |
480 |
Carton |
24x22x32=0.0167 |
32 |
33 |
1 |
1,Qality is first in our company.Our products have competitive price with good quality.
2, We also can produce according to your requirements. OEM is accepted.
3, If your goods is very complex, also it doesn't matter,we can provide integrated service.
4, We will reply your email or fax within 24h and you can call us at any time if there is any question on our products. We are sincerely hope we could have the oppotunity to cooperate with you in the future!
