TP-380S Intelligent digital display and magnetic electric jacket

standard packing

Specifications

electric heating jacket
Using electric jacket heating, with large heating area ,heating uniformity



SELON TP-380S INTELLIGENT DIGITAL DISPLAY AND MAGNETIC ELECTRIC JACKET



electric heating jacket, electric warmer jackets, electric steam jacket kettle



Product Numbers: TP-380S

Product description: Using electric jacket heating, with large heating area ,heating uniformity, rapid heating, the highest temperature can reach 380°C.

Product features:

1, Using electric jacket heating, with large heating area ,heating uniformity, rapid heating, the highest temperature can reach 380°C.

2, Using fuzzy PID control algorithm to control temperature, double screen digital display, High measurement accuracy ,small temperature difference , one button tick operating , internal and external thermocouple temperature measurement,, Silicon controlled rectifier control output, 160 - 240v wide voltage source and memory function in case of power-down.

3, Can heat up and stir the 50-20000ml standard or nonstandard reaction bottles.

4, Using the German PAPST series dc brushless motor, stable performance, low noise, long life, no spark.

5, The shell is made from strengthen PBT injection moulding shell, high temperature resistance, corrosion resistance, and good insulation performance.

6, 30 °slope control panel is suitable for viewing angle of sitting and standing.

7, Stepless speed adjustment, stable low speed, strong high speed.







Technical Parameter



Model	TP-380 Intelligent magnetic electric jacket	TP-380S Intelligent digital display and magnetic electric jacket
Adjustable temperature range	50-1800r/min, Stepless speed adjustment	50-1800r/min,Stepless speed adjustment,digital display
Adjustable temperature model	intelligent digital display temperature controlling, silicon controlled rectifier controlling
Adjustable temperature Accuracy	±1°C internal and external sensor
Heating temperature	The highest surface temperature can reach 380°C
Insulation layer	Non-alkali glass fiber, the heat resistance can reach 450°C
coefficient	relative humidity≤35%, will≥500 trillion
The temperature layer	use aluminum silicate cotton vacuum insulation body
Working Time	infinite
Power	220V,50Hz



 Technical Parameter of different models:



Model	100ml	250ml	500ml	1000ml
Capacity	50-100ml	250ml	500ml	1000ml
Boiling time	7—12min	7—12min	7—12min	7—12min
Heating power	130W	216W	230W	530W
Dimensions	260*155*155mm	260*155*155mm	260*155*155mm	325*215*175mm
Weight	2500g±50g	2500g±50g	2600g±50g	2800g±100g



Model	2000ml	3000ml	5000ml	10000ml
Capacity	2000ml	3000ml	5000ml	10000ml
Boiling time	10—15min	10—15min	15—20min	20—25min
Heating power	650W	730W	1100W	2100W
Dimensions	430*270*305mm	430*270*305mm	500*330*305mm	500*330*305mm
Weight	3000g±100g	3200g±100g	3500g±200g	4500g±300g
