1. We supply ISO standard brazed tips:A,B,C,D,E.
National Standard: A1,A2,A3,A4A,A5,A6, B1,B2,B3,C1,C2,C3,C4,C5,C1-A,D1,D2,E1,E2,E3,E4,E5, F1,F2,F3,S-A, S-B
| Type | Applications |
| A1 | For making periphery turning tools, boring tools and grooving tools. |
| A2 | For boring tools and end turning tools. |
| A3 | For making end and periphery turning tools. |
| A4 | For periphery turning tools, boring tools and turning tools. |
| A5 | For making straight shank periphery turning tools, boring through tools and mounting type and milling tools. |
| B1 | For making forming turning tools, planning and milling tools for maching dove tail grooves. |
| B2 | For making forming tools for machining concave radil and forming turning tools for railway wheels. |
| B3 | For making turning tools for radius machining. |
| B4 | For making concave turning tool and wheel edge turning tools. |
| C1 | for making threading turning tools & turning tools for the finishing of peripheries. |
| C2 | For making finishing turning tools and trapezoid threading turning tools. |
| C3 | for making parting tools and grooving tools. |
| C4 | for making grooving tools for machining wheels of triangular belts. |
| C5 | For making turning tools for the grooving of rolls in wheel flour production |
| C1-A | For making threading turning tools & turning tools for the finishing of peripheries. |
| D1 | For making milling tools, periphery turning tools and boring tools. |
| D2 | For making 3-edged milling tools, milling tools for T grooves and adjustable boring tools. |
| E1 | For making straight flue drills for machining non-metal and metal materials. |
| E2 | For making twist drills and straight flute drills. |
| E3 | For making keyway milling tools, end milling tools and broaching bits. |
| E4 | For making broaching drill bits. |
| E5 | For making hand-operated reamers and automatic reamers. |
| F1 | For making core clampers for lathes and periphery grinders. |
| Physical and mechanical properties of grades for cemented carbide brazed tips and their applications recommended | |||||
| ISO Code | Grade | Density | Hardness | T.R.S | Performance & application recommended |
| g/cm3 | HRA(HV) | MPα | |||
| K05 | YG3X | 15.1 | 91.5 | 1300 | Suitable for the finishing of cast iron and nonferrous metals and Yd05 can be used for the machining of hardening steel. |
| YG3 | 15 | 90.5 | 1300 | ||
| K10 | YG6X | 14.8 | 91 | 1560 | For the finishing & semi-finishing of cast iron and non ferrous metals and also for the machining of manganese steel and hardening steel. |
| YG6A | 14.7 | 91.5 | 1510 | ||
| K15 | YG6 | 14.9 | 89.5 | 1670 | Suitable for the roughing of cast iron and light alloys and also for the milling of cast iron and low-alloy steel. |
| K20 | YG8 | 14.6 | 89 | 1840 | |
| M10 | YS2T | 14.4 | 91.5 | 1960 | Suitable for the finishing and semi-finishing of stainless steel and conventional alloy steel. |
| YM10 | 12.2 | 91.5 | 1350 | ||
| YW1 | 13 | 91.5 | 1290 | ||
| M20 | YW2 | 12.9 | 90.5 | 1460 | the grade can be used for the semi-finishing of stainless steel and low-alloy steel and it is mainly used for the machining of railway wheel hubs. |
| P10 | YT05 | 12.6 | 92.5 | 1260 | Suitable for the finishing and semi-finishing of steel and cast steel with a moderate feed rate and a rather high cutting speed. |
| YT15 | 11.3 | 91 | 1300 | ||
| P25 | YT14 | 11.4 | 90.5 | 1400 | Suitable for the finishing and semi finishing of steel and cast steel. YS25 is specially used for the milling of steel and cast steel. |
| YS25 | 13 | 90.5 | 1780 | ||
| P25 | YT5 | 12.8 | 89.5 | 1570 | suitable for the heavy duty rough turning of steel and cast steel with a big feed rate at a medium and low speed under unfavorable working conditions |
| P40 | YC45 | 13.1 | 1320 | 1650 | Suitable for the heavy duty turning of steel and cast steel with a big feed rate and also for face milling. |
A1.Product Detailed Description:
Cemented carbide brazed tips are available fo finishing and semi-finishig cutting of cast iron,nonferrous metal&light alloy.Also for milling of manganess steel,quenched steel and low alloy steel.
A2.Our Packing Options:
B.Why Choose us ?
We are a tungsten carbide manufacturer, located in Zhuzhou City, Hunan Province, China. Our production are exported to UK, European, Japan, Taiwan and South-east Asia etc.
The products are popular in the market because of their good quality, moderate price and fast delivery.
C.Main Products:
1).carbide saw tips
2).carbide die cores
3).carbide brazed tips
4).carbide milling inserts
5). carbide disc cutters
6).carbide strips and plates
7).carbide mining and drilling tool parts
8).carbide rings and rollers
9).carbide wear resistant parts
10).carbide rods
D.Product Size:
All products according to ISO standard. For any other sizes or odd sizes,we are able to custom made according to clients' requirements or drawings.
E.Our advantage:
*100% quality guarantee(ISO9001)
*fexible payment terms(L/C, T/T, western union etc.)
*competitive price,10 years manufacturing experience
*fast delivery (7-10 workdays)
F.Factory Workshop Show:
G.Processing Chart:
H.OEM Service:
We will exert our best efforts to repay your appreciation for our products!
Please feel free to contact us as your convenient :)
Yeva.Yang (Sales Dept.)
