A. ground tungsten carbide slitting saw blade/polished saw cutters/fine grinding circular saw blade
with teeth
round saw blade
Application filed:
PCB tungsten carbide circular saw blade, namely electronic circuit board components feet of Cutting Machine Blade, based on solid carbide materials, through high-precision processing equipment and refined cut to form the blade of the cutting tool, mainly for cut legs on electronic circuit board of components feet, electronic foot, plug pin for cutting jobs in the electronics industry of blades.
Circuit board are the base of all electronic products, circuit board processing operations is also the basis for electronic manufacturing process, as the most popular and good performance cutting tool during the electronic circuit board industry, It is good job for cutting circuit board. PCB circuit board carbide blade supporting the use of foot cutter to cut legs,the main specifications have: 8 inches φ200 × φ70 × 3.5mm and 10-inch φ250 × φ70 × 3.5mm, mainly for manufacturing of the plug-in or other electronic products.
With extensive development of the electronics industry, the market demand for printed circuit boards, circuit board of carbide cutting tool inserts is hot developing during the cutting tool market. Circuit board of production mainly have two types: one is a plug-in solder pins, one is directly molded patch. Since patch forms of production needed more high-end production equipment, this is require very high investment, the most of the cutting plug-in still use circuit board of tungsten carbide circular saw blade.
| Properties and applications of tungsten carbide for Saw Cutters | |||||
| Grade | Performance & application recommended | ISO | |||
| Density | T.R.S | Hardness | |||
| g/cm3 | MPα | HRA | |||
| YG6A | 14.9 | 1850 | 92 | Fine grain alloy, good wear resistance. Semifinishing of chilled cast iron, non-ferrors metals alloys, semi-finishing and finishing of hardened steel, alloy steel. | K10 |
| YG8 | 14.8 | 2200 | 89.5 | High strength in use, impact and shock resistance higher than YG6, but wear resistance and cutting speed comparatively lower. Roughing of cast irons,non-ferrors metals and their alloys as well as non metallic materials at low cutting speed. | K20 |
| YG10X | 14.5 | 2200 | 91 | Fine grain alloy, good wear resistance. Used for processing hard wood,veneer board,PCB,PVC andmetals. | K10~ K20 |
| YS2T | 14.5 | 2480 | 92 | Fine grade alloy, with high wear resistance, high bending strength, high resistance to bonding, high thermal strength. Machining of refractory alloys,stainless steel and high manganese steel, etc. | K10~ K20 |
| Other grades may be offered by customers’ requirements. | |||||
B.Why Choose us ?
We are a tungsten carbide manufacturer, located in Zhuzhou City, Hunan Province, China. Our production are exported to UK, European, Japan, Taiwan and South-east Asia etc. The products are popular in the market because of their good quality, moderate price and fast delivery.
C.Main Products:
1).carbide saw tips
2).carbide die cores
3).carbide brazed tips
4).carbide milling inserts
5). carbide disc cutters
6).carbide strips and plates
7).carbide mining and drilling tool parts
8).carbide rings and rollers
9).carbide wear resistant parts
10).carbide rods
D.Product Size:
All products according to ISO standard. For any other sizes or odd sizes,we are able to custom made according to clients' requirements or drawings.
E.Our advantage:
*100% quality guarantee(ISO9001)
*fexible payment terms(L/C, T/T, western union etc.)
*competitive price,10 years manufacturing experience
*fast delivery (5-10 workdays)
F.Factory Workshop Show:
G.Processing Chart:
H.OEM Service:
We will exert our best efforts to repay your appreciation for our products!
Please feel free to contact us as your convenient :)
