Specifications
1.welder Suitable for welding thin plate2.good arc starting and high qulity welding surface
3.CE GS ROHS
continous
ARC TIG Welding machine
| Item | TIG-100 | TIG-130 | TIG-150 |
| Power voltage | 115/230 | 230 | 230 |
| Frequency(HZ) | 50/60 | 50/60 | 50/60 |
| Rated input current(A) | 12 | 16 | 20 |
| No-load voltage(V) | 80 | 80 | 80 |
| Output current ajustable range(A) | 5-85 | 5-120 | 5-140 |
| Rated duty cycle(%) | |||
| Efficiency(%) | 75 | 83 | 83 |
| Insulation class | H | H | H |
| Protection class | IP21 | IP21 | IP21 |
| Mesurement(MM) | 365*230*330 | 365*230*330 | 365*230*330 |
| Power factor | 0.9 | 0.9 | 0.9 |
| Weight(KG) | 7 | 7 | 7 |
| Cod(NO) | 892004 | 892005 | 892006 |
SUPER 200A TIG/MMA AC/DC WELDING MACHINE
Features:
*Quility suqare wave power supply ,stable arc ,HFarc stabilization not necessary
*Concentrated heat ,easy to fill in the wire ,especially suitable for wire welding in industry ,etc
*Foot pedal controller connection facilitates welder's operation
*Built -in alarming and protective circuits are provided to prevent over current , over heat ,over *voltage ,low voltage ,etc and ensure safe operation
*High duty cycle ,continuous operation without interruption at large current is available
*Suitable for welding of various metallic materials suchu as alunminum ,alunminm alloy ,carbon *steel ,stainless steel , copper , titanium .etc.
SUPPLY:
OEM sevice offered, Free spare parts, Technical help to exporters, Design Service Offered, Buyer Label Offered .
MAIN MARKET:
Europe, South America , Southeast Asia, Mid East ,North America.
ACCESSORIES:
With welding torch,earth clamp,electrode holder,mask,brush.
CERTIFICATE:
CE,ROHS,GS,ISO9001
| ITEM | TIG 200P AC/DC |
| Power voltage(V) | 1ph AC 220V +-15% |
| Frequency(HZ) | 50/60 |
| Rated input current (A) | 28 |
| Output current range (A) | TIG 10-200 MMA 10-150 |
| Delay times(S) | 1-10 |
| Fall times(S) | 0-10 |
| No-load voltage (V) | 56 |
| Rated duty voltage (V) | TIG 18 MMA 26 |
| PULSE FREQUENCY(Hz) | 0.5-5 |
| PULSE WIDTH(%) | 10-90 |
| AC BALANCE(%) | 20-80 |
| CUREENT FALL TIME(s)[4t] | 0-10 |
| Remote control | yes |
| Arc initiation way | HF |
| Duty cycle (%) | 60 |
| Efficiency (%) | 80 |
| Insulation class | F |
| Protections class | IP21S |
| Weight(KG) | 20 |
| Measurement(MM) | 498*328*302 |
| Cod.(NO) | 112003 |
TIG WELDING DETAILS:
In TIG welding (Tungsten inert gas), the welding arc is formed between a non-consumable tungsten electrode and the work piece. The shielding gas is an inert gas that does not affect the welding process per se. Usually the shielding gas is argon and it protects not only the molten weld but also the electrode in the torch from oxygenation.
A filler material may not be necessary in TIG welding. The pieces can be fused also by melting the groove together. If a filler is used, it is fed into the molten weld manually and not through the weld torch as in MIG/MAG welding. Therefore, the TIG welding torch has a completely different structure than a MIG/MAG torch.
Various TIG welding methods include, for example, the DC TIG welding method that uses direct current, AC TIG welding that utilises alternating current, and pulse TIG.
Why not try one sample first?Choosing our products,give yourself maximum profit. Inquires are typically answered within 24 hours.
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
