IGBT Inverter Digital AC DC TIG Welder for sale
Features:
1) IGBT Inverter System, advanced PWM technology.
2) Digital controlling system, 16 byte MCU inside.
3) 2 Working Modes: DC TIG/ MMA.
4)40% heavy duty cycle.
5) Refined arc ignition from 5A.
6) Perfect pulse control system, Smooth welding quality.
7) 2T/4T control mode, HF/LIFT TIG ignition.
8) Remote current controls system(need optional torch).
9) PFC technology for ultimate energy efficienty(optional).
| Item No | TIG-160Di | TIG-200Di |
| Input Voltage | 1PH~,220-240V,50/60Hz | 1PH~,220-240V,50/60Hz |
| Max. Input Capacity | 5.3KVA | 7.0KVA |
| No-load Voltage | 56-62V | 56-62V |
| Rated Output Current/Voltage | TIG:160A/16.4V | TIG:200A/18V |
| MMA:160A/26.4V | MMA:200A/28V | |
| Rated Duty Cycle(40°C) | 40% | TIG:40% / MMA:25% |
| Pulse Frequency Range | 0.2-100Hz | 0.2-100Hz |
| Pulse Width Range | 1-100% | 1-100% |
| Current Up-slope Time | 0.1-10S | 0.1-10S |
| Current Down-slope Time | 0.1-10S | 0.1-10S |
| Arc Force / Retard Time | Adjustable | Adjustable |
| Gas Pre-flow/Retard Time | 0.1-10S | 0.1-10S |
| Dimension(LxWxH) | 400x140x230mm | 400x140x230mm |
| Weight | 7.5KG | 8KG |
Why not try one sample first?Choosing our products,give yourself maximum profit. Inquires are typically answered within 24 hours.
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
