Specifications
mig-250 igbt inverter co2 mig welding machine1,IGBT and Mosfet
2,portable type
3,CE certification
4,OEM service
Newest design mig-250y igbt inverter co2 mig welding machine manufacture
| Why choose us? |
1. 20 years - Andeli Group Co.,Ltd is founded in 1993. |
Application:
1. Suitable for welding metal plate with thickness above 0.8mm
2. Low cost but with high effciency
3. Both output current and voltage could be adjustable to satisfy different welding reuqirement
4. Small splashing,great penetration
5. Two options of wire feeder: built-in or separated
Specification:
| Inverter CO2 Gas Shielded Welding Machine (Y: All in one, F: Separate Machine ) | ||||
| Model | MIG-200Y | MIG-250Y | MIG-200F | MIG-250F |
| Type | MOSFET | |||
| Rated input voltage (V) | single phase AC220 ±15% | three phase AC380 ±15% | single phase AC220 ±15% | three phase AC380 ±15% |
| Rated frequency (Hz) | 50/60 | |||
| Rated input current (A) | 23.5 | 10.5 | 23.5 | 10.5 |
| Output current (A) | 180 | 220 | 180 | 220 |
| Output voltage (V) | 23 | 25 | 23 | 25 |
| Duty cycle (%) | 60 | 60 | 60 | 60 |
| Efficiency (%) | 85 | 85 | 85 | 85 |
| Power factor | 0.93 | 0.93 | 0.93 | 0.93 |
| Diameter of wire (m) | 0.8 | 1.0 | 0.8 | 1.0 |
| Type of wire feeder | built-in | built-in | separated | separated |
| Net weight of machine(KG) | 33.7 | 35.2 | 11.9 | 13.7 |
| Gross weight of machine packing(KG) | 40 | 41.3 | 13 | 14.8 |
| Gross weight of accessories packing (KG) | - | - | 16.3 | 16.3 |
| Dimension of machine (mm) | 630×315×695 | 630×315×695 | 500×210×370 | 500×210×370 |
| Dimension of packing- machine (mm) | 660×370×750 | 660×370×750 | 560×270×460 | 560×270×460 |
| Dimension of packing-wire feeder (mm) | - | - | 555×435×410 | 555×435×410 |
| including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, pressure regulator×1pcs, MIG torch×1pcs, | ||||
| additional accessories for MIG-200F/MIG-250F: double drive wire feeder×1pcs, control cable×5meters | ||||
Our Competive:
Strong Welding Capacity:
Other details:
* BUY WITH CONFIDENCE.
* QUALITY MACHINES MANUFACTURED BY ANDELI.
* FULL SERVICE AND PARTS BACK UP.
* 24 MONTHS WARRANTY.
1. Q: Do you have your own factory?
A: Yes, we have. Our factory located in Yueqing city, Zhejiang province.
2. Q: How can I visit your factory?
A: Before you take off from your country, please let us know. We will show you the way,or arrange time to pick you up if possible.
3. Q: Could you print our company LOGO on the nameplate and package?
A: Yes, we can do that.
4.Q:What is the Minimum Order Quantity?
A:Moq usually be 100pcs. Small quantity is also available.
5.Q:Is sample available and the sample fee refundable?
A: Yes, sample fee will be return back in your next formal order.
6.Q:What is the available shipping way?
A: Small quantity usually choose DHL, Fedex, UPS and EMS etc.international door to door express.
Bulk order would be sea/ air shipping.
Package&Shiping
Usually the machines are packed by carton.Big welding machines are packed in wooden box .
- OEM is available
- Deliver time:If there have stock,we will delivery the goods 3-7 work days after received payment. Otherwise,we will delivery it 25-30 work days after received payment.
- Payment:we can accept T/T,Western Union,L/C,Aliexpress Escrow
- Gurantee and aftersale servieces:
- 1 years warranty for all items
- 1%-2% Free spare parts will be provided for repairment.
- Maintenance manual
- 24 hours support by e-mail
- For Large Order,Engineer can be sent to your country for on-site maintenance instructions
