AIJ high accuracy Temperature Controller
Main Features for AIJ Pt100 INPUT High accuracy Temperature Controller
- Use digital calibration technology for input measurement with input measurement accuracy F.S.0.05%, support standard thermocouples and RTDs, maxium resolution is 0.01℃.
- Use advanced artificial intelligent control algorithm, no overshoot and with the function of auto tuning (AT) and self-adaptation.
- Use advanced modular structure, conveniently providing plentiful output options, able to satisfy the requirements of various applications, make quick delivery and convenience the maintenance of the instrument.
- Friendly and customized operating interface leads to quick and easy to operate. Parameter can be promoted to immediate operator access in Field Parameter Table or password protected in Full Parameter Table.
- With worldwide power supply of 100-240VAC or 24VDC and various installation dimensions for users to choose.
- ISO9001, CE and UL 61010-1 certified, achieving world class level of quality, anti-interference ablility and safety.
Technical Specifications for AI-516PB Pt100 Modbus RTU Temperature Controller
1. Input type:
Thermocouple: S(-50~+1760℃), K(-270~+1370℃), E(-270~+1000℃), J(-210~+1200℃), T(-270~
+400℃) ,
R(-50~+1760℃), B(40~+1820℃), N(-270~+1300℃), WRE3-WRE25(0~+2310℃) ,
WRE5-WRE26(0~+2310℃) , F2(700~+2000℃)
Resistance temperature detector: PT100(-200~+850℃) , PT1000(10~+100℃) , CU50(-50~+150℃), RF(0~300K)
(MV): -10~120MV
(Ω): 0~500Ω, 900~1200Ω
(V): I5:0~5V, I10:0~10V, I200:0~200V, I500:0~500V
(MA) : I2:0~20MA, I4:4~20MA
2. Measurement accuracy:
0.05%FS
3. Control mode:
Relay
SSR
Triac
4. Alarm function:
High limit, Low limit, deviation high limit and deviation low limit; providing the function of alarm blocking at the beginning of power on.
5. Temperature shift:
≤0.015%FS/℃ (typical value is 80ppm.℃)
6. Samplingperiod:
0.2 second.
7. Power supply voltage rating:
100-240VAC, -15%, +10% / 50-60Hz.
8. Power consumption:
≤5W.
9. Operation ambient:
Temperature: -10~+60°C, Humidity: 0~90%RH.
Front Panel and Operation for AI-516PB Pt100 Modbus RTU Temperature Controller
You will get:
- A piece of temperature controller;
- A paper of user manual;
- 5-year warranty card and Quality Approval card;
- A lable of units;
- A pair of installaton brackets;
- Nice package carton box with Yudian logo.
- Factory with 26 years experience.
- Three to ten years warranty time.
- Quick delivery ( within 3 working days).
- Retail/ Wholesale/ OEM/ ODM available.
- Better price for bulk order.
- We provide after sales service and technical assistance as customers requirement and needs.
