Ring Die Pellet Mill Pellet Soya Lecithin Granules for Poultry

Ring Die Pellet Mill Pellet Soya Lecithin Granules for Poultry photo-1
US$ 1,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
DERRY
Model Number:
HK250
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Brand Name DERRY
Model Number HK250
Type Feed Pellet Machine
Voltage 380V50HZ3Phase
Power(W) 22
Dimension(L*W*H) 1300*1000 *1500
Weight 370 kg
Certification CE/ISO/SGS
Warranty One year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Soya Lecithin Granules
1: High-efficiency gear driving
2: Pellet size : 2-18 mm
3: Low energy consumption
4:ISO/CE/SGS

Ring Die Pellet Mill Pellet Soya Lecithin Granules for Poultry





Workprinciple of Soya Lecithin Granules


A.  The Soya Lecithin Granules is easy to operate, we will install the machine and test machine well before delivery, once user connect it with electric power, and the raw material is delivered into the Pellet Machine through a conveyor and then conveyed into a rotating ring die by a feeder.

B.  Finely pulverized material will be pressed into ring die through two rotating press rollers.
The resulting pressure compresses the material and extrudes it through the holes in the die. The pellet will be out directly.





Technical Parameters of Soya Lecithin Granules


Model

HK250

HK304

HK320

HK350

HK400

HK420

HK508

Capacity

(T/H )

0.5-1.5

1-2

2-4

3-7

7-10

5-14

6-20

Power (kw)

22

30

37

55

75/90

90/110

132/160

Screw feeder power (kw )



0.75



0.75





0.75



0.75



1.5



1.5



2.2

Conditioner power (kw )

2.2

2.2

2.2

2.2

5.5

5.5

11

Die Inner Dia(mm)

Φ250

Φ304

Φ320



Φ350



Φ400



Φ420



Φ508

Dimension (L*W*H)

1300*1000

*1500

1200*1000

*1100

1900*900

*1100

1900*900

*1100

3300*1200

*2500

3300*1200

*2505

3500*1470

*2800

Weight(KG)

370

500

1300

1625

2000

2200

2400

Pellet size

2-18mm





More Pictures of Soya Lecithin Granules



Ring Die Pellet Mill Pellet Soya Lecithin Granules for PoultryRing Die Pellet Mill Pellet Soya Lecithin Granules for PoultryRing Die Pellet Mill Pellet Soya Lecithin Granules for PoultryRing Die Pellet Mill Pellet Soya Lecithin Granules for PoultryRing Die Pellet Mill Pellet Soya Lecithin Granules for PoultryRing Die Pellet Mill Pellet Soya Lecithin Granules for PoultryRing Die Pellet Mill Pellet Soya Lecithin Granules for Poultry







If you are interested in our machines ,pls contact with us without hesitation,







and also let us know:







1: What's your raw material ?







2: The capacity you need ?







We will reply you within 24 hours.
