Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Loader > SZ-918 Wheel Loader
SZ-918 Wheel Loader
US$ 14,000 - 14,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
Shenwa
Model Number:
SZ-920 Shenwa International FZE
Payment & Shipping
Payment Methods:
Port of Shipment:
Shangdong Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Brand Name
Shenwa
Model Number
SZ-920 Shenwa International FZE
Place of Origin
Shandong, China
Type
Mini Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
5850*2550*2700
Rated Load
2000kg
Certification
ISO SGS
Warranty
1 year
After-sales Service Provided
Overseas service center available
Specifications
Streamlined appearance design,elegant and generous.Complete hydraulic changing direction system,reliable performance,convenien
SPECIFICATIONG:
Streamlined appearance design,elegant and generous.
Bucket can be set level automatically,computer is adopted to optimize design,single tipping bucket cylinder,"Z" type turning bucket structure,to realize the enormous shovel digging forces.
Gearbox and torque device has integral structure,reliable performance.
The dynamical system selects the engine of model 4102,reliable performance,high efficiency and economizing on fuel.
Complete hydraulic changing direction system,reliable performance,convenient operation.
Can allocate many kinds of selectable assembly such as wooden fork,pipe fork,grass fork,stone bucket,enlarged bucket etc,to meet the needs of various working states.
PARAMETERS:
| TECHNICAL | PARAMETERS |
|---|---|
| Total Weight | 4000kg |
| Overall Dimension | 5850*2550*2700 |
| Bucket Capacity | 1.03m3 |
| Rated Weight | 2000kg |
| Max. Dumping Height | 3200mm |
| Max. Lifting Height | 4465mm |
| Max. Breakout Force | 32kn |
| Distance Between Axles | 2140mm |
| Distance Between Wheel | 1480mm |
| Sum Time | 9s |
| Max. Dumping Distance | 1100mm |
| Max. Walking Speed | 24km/h |
| Min. Rotary Radius | 3500mm |
| Engine Model | 4102 |
| Rated Power | 47km |
| Rated Revolution | 2400r/min |
