Home > Industrial Equipment & Components > Refrigeration Equipment > Industrial Air Conditioner > 50HZ 24000BTU Window Type Air Conditioner
50HZ 24000BTU Window Type Air Conditioner
Negotiable
MOQ: 300 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
ZESUN or OEM
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mechanical Window Type Air ConditionerNegotiableMOQ: 300 Sets -
Favorable 60Hz Window Air ConditionerNegotiableMOQ: 300 Sets
-
7000Btu to 30000Btu Cooling Only Window Air ConditionerNegotiableMOQ: 300 Sets
-
18000BTU Window Air ConditionerNegotiableMOQ: 100 Sets
-
2 Ton Cheap Small Window Type Air Conditioning UnitNegotiableMOQ: 100 Sets
Condition
New
Brand Name
ZESUN or OEM
Place of Origin
Guangdong, China
Use
Room
Power Source
Electrical
Power Type
AC
Type
Window Mounted Air Conditioners
Cooling/Heating
Cooling/Heating
Certification
CB, CE, CSA, EMC, GS, Other, SASO, UL, CB, CE, CSA, EMC, GS, RoHS, SASO, UL
Capacity (btu)
9000
COP
2.64
EER
3.0
Power (W)
2500
Voltage (V)
220
Model Number
F
Specifications
1.Slide chassis2.Easu-clean panel&filters
Feature
- Energy saving
- Easy demounting and washing filter net
- Independent dehumidification
- Sleeping mode design
- Three-dimensional airflow
- Directional airflow and fresh air function
- Easy to install and operate
- Timed switch-off and switech-on
| Model | MWF1-07CM-QB4 | MWF1-09CM-QB4 | MWF1-12CM-QB4 | MWF-18CM-QB2 | MWF-24CM-QB2 | MWF-30CM-QB2 | ||
| Power supply | Ph-V-Hz | 1Ph ,220-240V~,50Hz | 1Ph ,220-240V~,50Hz | 220-240V~ 50Hz, 1Ph | 1Ph ,220-240V~,50Hz | 1Ph ,220-240V~,50Hz | 1Ph ,220-240V~,50Hz | |
| Cooling | Capacity | Btu/h | 7000 | 9000 | 12000 | 18000 | 24000 | 30000 |
| Input | W | 850 | 1030 | 1500 | 2100 | 2928 | 3660 | |
| Rating current | A | 3.8 | 4.5 | 6.8 | 9.7 | 13.3 | 15.2 | |
| EER | W/W | 2.41 | 2.41 | 2.34 | 2.41 | 2.21 | 2.21 | |
| Moisture Removal | L/h | 0.8 | 1 | 1.2 | 1.6 | 2.2 | 2.5 | |
| Max. input consumption | W | 1100 | 1160 | 1800 | 2500 | 3500 | 4000 | |
| Max. current | A | 5.1 | 6.2 | 8.8 | 12 | 18 | 19 | |
| Starting current | A | 17.6 | 18 | ------ | 41.2 | 75 | 66 | |
| Compressor | Model | PH120X1CY-4BGDE2 | PH150M1B-4DZD2 | PH215M2C-4FT | PH290X2C-4FT1 | QP407PAA | QP442PAD | |
| Type | ROTARY | ROTARY | ROTARY | ROTARY | ROTARY | ROTARY | ||
| Brand | GMCC | GMCC | GMCC | GMCC | LG | LG | ||
| Capacitor | uF | 25 | 30 | 35 | 35 | 60 | 50 | |
| Indoor air flow (Hi/Mi/Lo) | m3/h | 360/330/280 | 360/330/280 | 512/444/376 | 780/690/570 | 740/650/560 | 820/710/590 | |
| Indoor noise level (Hi/Mi/Lo) | dB(A) | 50/48/45 | 50/48/45 | 54/51/47 | 57/54/51 | 55/52/49 | 61/58/55 | |
| Outdoor air flow | m3/h | 680/610/540 | 680/610/540 | 1079/921/767 | 1620/1460/1270 | 1460/1320/1150 | 1460/1320/1150 | |
| Outdoor noise level | dB(A) | 57/55/52 | 57/55/52 | 62/58/55 | 62/59/56 | 62/59/56 | 67/64/61 | |
| Refrigerant type | kg | R22/0.26 | R22/0.28 | R22/0.4 | R22/0.5 | R22/0.75 | R22/0.73 | |
| Design pressure | MPa | 2.6/1.0 | 2.6/1.0 | 2.6/1.0 | 2.6/1.0 | 2.6/1.0 | 2.6/1.0 | |
| Plug type | 1.0x3/VDE | 1.0x3/VDE | 1.5x3/VDE | 1.5x3/VDE | 2.5x3/no plug | 2.5x3/no plug | ||
| Thermostat type | Mechanical Control | Mechanical Control | Mechanical control | Mechanical control | Mechanical control | Mechanical control | ||
| Application area | m2 | 10-17 | 12-21 | 18-29 | 23-39 | 31-51 | 34-57 | |
| Dimension(W*D*H) | mm | 450x535x346 | 450x535x346 | 600x560x380 | 660x680x428 | 660x680x428 | 660x680x428 | |
| Packing (W*D*H) | mm | 495x580x435 | 495x580x435 | 685x620x430 | 725x795x475 | 725x795x475 | 725x795x475 | |
| Net/Gross weight | Kg | 25/27 | 26/27.5 | 43/47 | 48/50 | 58/62 | 59/63.5 | |
| Qty’per 20’ /40’ /40'HQ | 220/480/576 | 220/480/576 | 135/285/342 | 113/225/225 | 113/225/225 | 113/225/225 | ||
220V-50Hz-R22-T3-Cooling&Heating Specification:
