Specifications
1,Working table controled by microcomputer,water temperature,oil temperature,current,work timing are all insight.-
- Max. digging depth 3300mm
- Max. digging height 5300mm
- Max. digging radius 5700mm
- Max. dumping height 3900mm
- Engine Model 4102
- Rated Power 44KW
- Total weight 5600kg
- bucket capacity 0.28m3
- Hydraulic system pressure 20Mpa
- Max. flow 25ml/r/25ml/r
- Working efficiency 60-80m3/h
- Working times 3-5times/min
- Gradeability 25%
- Max. hauling force 27.4kn
- Walking speed <=35km/h
- Max. swing angle of Boom 360°
- Overall Dimensions(L*w*H) 6080*1980*2870
- Wheelbase 2000mm
- Min. ground clearance 220mm
Performance characteristics |
|
|
1,Working table controled by microcomputer,water temperature,oil temperature,current,work timing are all insight. 2,Cabin room working table can opern fast and convenient to make maintain machinery quickly.And can near start motor,engine,battery,rotary motor,speed reducer,swivel connection,valve,tube accessiblely,can reduce time of mainterance. 3,Famous brand hydraulic components are adpoted,of which the operating life is long,the power is driving and the operating speed is fast. 4,Fully hydraulic steering,with two pilot hand levers to operate,which |
|
|
is flexible,portable,efficient and fast. 5,Scuttle with pneumatic spring can provide upward eyeshot and extral ventilation effect. 6,Slidable folding front screen,easy to open and hold at the open position,which ameliorates running conditions efficiently. 7,Famous hydraulic traction motor is adopted,the speed of which can be adjusted with an extensive range. 8,Adjustable vibration damper seat,comfortable,accords with the requirements of ergonomics. 9,Ascendant performance of complete appliance,with extraordinary operation efficiency. 10,With which many kinds of optional components can be matched to meet requirements of different users. |
|
|
Update Date:2010-10-19 02:11:21
