SZ15-10 Backhoe Loader

SZ15-10 Backhoe Loader thumbnail-1
SZ15-10 Backhoe Loader photo-1
US$ 15,000 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
shenwa
Model Number:
SZ15-10
Contact Supplier Request Quote Chat Now
Qingzhou Shenwa Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Brand Name shenwa
Model Number SZ15-10
Place of Origin Shandong, China
Type Backhoe Loader
Moving Type Wheel Loader
Dimension(Long * Breadth * High) 5400*1620*2650mm
Rated Load 1000kg

EXCAVATOR  PART

MAX.DIGGING DEPTH

 MAX.DINGGING HEIGHT

 MAX.DIGGING RADIUS

 MAX.DUMPING HEIGHT

 BUCKET CAPACITY

 WORKING EFFICIENCY

 WORKING TIMES

MAX. HAULING FORCE

MAX. SWING ANGLE OF BOOM

2100mm

4000mm

4500mm

3000mm

0.2m3

20-40m3/h

3-5Times/min

23kn

180°

LOADER  PART

MAX.DUMPING HEIGHT

MIN. ROTARY RADIUS

MAX.DUMPING DISTANCE

RATED LOADING MASS

LIFTING TIME OF MOVABLE ARM

LIFTING TIME OF MOVABLE ARM

SUMMATIONAL TIME

MAX. BREAKOUT FORCE

2400mm

3500mm

900mm

1000kg

4.5s

3s

10s

20kn

ENGINE

MODEL

RATED POWER

RATED REVOLUTION

YC2105

27kw

2200r/min



SPECIFICATION

WORKING PRESSURE

MAX.FLUX

TOTAL WEIGHT

GRADEABILITY

WALKING SPEED

DISTANCE BETWEEN AXLES

MIN. GROUND CLEARANCE

OVERALL DIMENSION(L×W×H)

20MPa

25ml/r/25ml/r

3700kg

25%

≤20km/h

1725mm

230mm

5400×1620×2650mm

















































Performance Characteristics:

 Enlarged operator cabin, with secure glass, is capacious and Brightsome.



 Working table, water temperature, oil temperature, current, work timing are all insight.



 Famous brand hydraulic components are adopted, tow gear oil pump work together, the power is driving and loading and dumpingcan change freely.



 Adjustable seat, convenient and comfortable to use.



 Rear and front body, with smell rotary radius, hydraulic steering,comfy and convenient to operate.



 Hydraulic traction, the moving arm can leveled skid and expend digging range.



 Completely have the all functions of minitype digging machines.



 Ascendant performance of complete appliance, with extraordinary operation efficiency.



 With which many kinds of optional components can be matched to meet requirements of different users
