Help CenterBackhoe Loader
Related Products
ENGING
MODEL 4105
RATED POWER 59KW
RATED REVOUTION 2400r/min
HYDRAULIC SYSTEM WORKING PRESSURE 16Mpa
MAX.FLUX 63ml/r/63ml/r
SPECIFICATIONS
TOTAL WEIGHT 5500kg
GRADEABILITY 25%
WALING SPEED <=39kn/h
DISTANCE BETWEEN AXLES 2700mm
MIN.GROUND CLEARANCE 250mm
OVERALL DIMENSION(L*W*H) 7600*2005*2700
WORKING RANGE OF GRAB
MAX.DIGGING DEPTH 3000mm
MAX.DIGGING HEIGHT 5600mm
MAX.DIGGING RADIUS 5200mm
MAX.DUMPING HEIGHT 4300mm
WORKING RANGE OF LOADER
MAX.DUMPING HEIGHT 2900mm
MIN.GROUND CLEARANCE 5000mm
MAX.DUMPING DISTANCE 950mm
SPECIFICATIONS OF GRAB
BUCKET CAPACITY 0.4m3
WORKING EFFICIENCY 30-60m3/h
WORKING TIMES 4-7times/min
MAX.HAULING FORCE 29kn
MAX.SWING ANGLE OF BOOM 180
SPECIFICATIONS OF LOADER
RATED LOADING MASS 1500Kg
LIFTING TIME OF MOVABLE ARM 3.5s
SUMMA TIONAL TIME 7.0s
MAX.GROUND CLEARANCE 10.5kn
