Power cord port industrial used Certificated rubber steel cord conveyor belt
Power cord port industrial used Certificated rubber steel cord conveyor belt
Payment: T/T, L/C
Certificate: CE,SGS,ISO,TUV
Warranty: More than 2 years.
OEM/ODM available.
| Item | Steel cord conveyor belt |
| Cover material | NR/CR/NBR/EPDM/SBR |
| Belt cord material | ST |
| Belt width | 500-2400 mm |
| Length | 100 meters or as your request |
| Cover thickness | 6mm-11mm |
| Tensile strength | 500-3000N/mm |
| Structure | flat |
| Types | Steel cord |
| Standard |
GB/T9770, DIN22131, EN ISO 15236, SANS1366 and AS1333 |
| Payment terms | FOB XINGANG |
| Shipment | By sea |
| Application |
Metallurgy, steel plant, building material and construction, energy, chemical, machinery equipment and port. |
| The Quantity of the Core | |||||||||
| Specificaiton | Belt Width mm | ||||||||
| 650 | 800 | 1000 | 1200 | 1400 | 1600 | 1800 | 2000 | 2200 | |
| ST630 | 60 | 75 | 95 | 113 | 133 | 115 | |||
| ST800 | 60 | 75 | 95 | 113 | 133 | 115 | 171 | ||
| ST1000 | 50 | 63 | 79 | 94 | 111 | 126 | 143 | 159 | 176 |
| ST1250 | 50 | 63 | 79 | 94 | 111 | 126 | 143 | 159 | 176 |
| ST1600 | 50 | 63 | 79 | 94 | 111 | 126 | 143 | 159 | 176 |
| ST2000 | 50 | 63 | 79 | 94 | 111 | 126 | 143 | 159 | 176 |
| ST2500 | 40 | 50 | 64 | 76 | 89 | 101 | 114 | 128 | 141 |
| ST2800 | 40 | 50 | 64 | 76 | 89 | 101 | 114 | 128 | 141 |
| ST3150 | 40 | 50 | 64 | 76 | 89 | 101 | 114 | 128 | 141 |
| ST3500 | 50 | 64 | 76 | 89 | 101 | 114 | 128 | 141 | |
| ST4000 | 50 | 64 | 76 | 89 | 101 | 114 | 128 | 141 | |
| ST4500 | 59 | 71 | 84 | 96 | 109 | 121 | 134 | ||
| ST5000 | 55 | 66 | 78 | 90 | 102 | 113 | 125 | ||
| ST5400 | 55 | 66 | 78 | 90 | 102 | 113 | 125 | ||
| ST6300 | 59 | 69 | 80 | 90 | 101 | 111 | |||
| ST7000 | 59 | 69 | 80 | 90 | 101 | 111 | |||
| ST7500 | 54 | 63 | 72 | 82 | 91 | 100 | |||
| Main Types Standard of Steel Core Conveyor Belt | ||
| Series | Types | Standard |
| 1 | Common | GB/T9770-2013, DIN22131-88, AS1333-94 |
| 2 | General Flame Resistance | HG2539-93, GB/T9770P, DIN22131K, reference GB/T10822 |
| 3 | Flame Resistance | MT668-2008, GB21352-08, AS1333 |
| 4 | Anti-Tearing | HG/T3646-99 |
| 5 | Heat Tesistance | HG/T2297-92, GB/T20021-2005 |
| 6 | Wear Resistance | GB/T9770D, DIN22131W |
| 7 | Cold Resistance | HG/T3647, GB/T9770P |
Power cord port industrial used Certificated rubber steel cord conveyor belt
Power cord port industrial used Certificated rubber steel cord conveyor belt
1. Package: Water proof cloth
2. Loading port: Tianjin, Shanghai or according to customer's requirement
3. Delivery Time: 3 -5 working days for samples
10-13 days for each 20ft containers
13-15 days for each 40ft containers
1.What is your mainly product?
Our mainly product as :
EP/NN/CC56 conveyor belt,PVC PVG solid woven conveyor belt, Steel cord conveyor belt.The PVC PVG solid woven fire-resistant belt is our advantage.
2. What about the specification, standard or nonstandard? Can we product in your special requirements?
Most of our belts are nonstandard and of course we can produce in your requirements. For those standard products, you can chose your sizes of different width, length and also thickness.
3.What is the your MOQ?
The MOQ is 100-200mtr any kind of belt. that is too say :1-2 rolls
4. What about the samples?
We can supply some free samples if you have a DHL, TNT, UPS or FedEx account or other courier freight collectable account and agree to pay the courier freight.
a.If you don't have courier account, you can send your courier to collect samples from our company, or send us the the courier cost and we will arrange the sample for you.
b.The charge both sample and courier cost will be return you once the mass order placed.
5. What’s your advantage?
a. Reasonable price
b. High quality production
c. Fast production period
d. Quick delivery
e. Stable product supply
- Any Inquires will be replied within 24 hours.
- Professional manufacturer,we have professional team to design and manufacture conveyor belt as customer requested.
- All of our products 100% inspection before shipment, we guarantee to use our products safety.
- We own the best after-sale service.If there any problems happen, our team will do our best to solve for customers.
- Faster delivery, 7-10 days after we receive the payment.
- Any problems during use, you can freely contact with us by email or by telephone.
- Sample is available.
- OEM or ODM is possible.
