Low temperature storage tank is composed of a vaccum carbon steel shell and a pressure vessel inside the shell.It is operated in low to medium pressure. The safety relief device is used to protect the built-in pressure container and vaccum shell.Its use and the model is based on GB150 and the specification. The safety relief device includes a compound relief and a esplosion-proof to protect the vaccum shell . Tank is designed according to the safe, duable and reliable operation.
Luxi New Energy Equipment Group Co., Ltd. is specialized in producing all types of CNG, LNG cylinders and gas equipment.
Our company belongs to Luxi Group Corp., which is a large, state-owned chemical enterprise group. We are an integrated chemical enterprise of compound fertilizer, chemical engineering and chemical equipment.
Our company covers an area of 20 million square meters, with the plant construction area of 100, 000 square meters. Our company currently employs more than 300 people, and all kinds of professional personnel of more than 60 people, including high, intermediate professional titles of more than 20 people.
|
|
| type |
30m³/0.8
|
LO2/LN2/LAr |
|
working temperature/°C |
-196 |
working pressure/MPa |
0.8 |
inner shell thickness |
10/10 |
design temperature/°C |
-196 |
design pressure/MPa |
0.84 |
pneumatic test pressure/MPa |
1.08 |
leakage tect pressure/MPa |
0.84 |
main pressure units |
Q235B/S30408 |
total volume/m³ |
31.6 |
effective volume/m³ |
30 |
filling coefficiency |
0.95 |
dimension |
2520×12060 |
With A1, A2, B1, B3 grade pressure vessel manufacturing, C3 -class container tube bundle assembly, C2 -level mobile pressure vessel manufacturing qualification, we have passed 9000 quality management system and France BV international product certifications.
We use the most advanced production line equipment, large punching machine, large rolling machine, CNC automatic welding machine, vacuum unit, CNC spinning shut, closed end equipment, automated heat treatment equipment, CNC winding equipment, electrostatic spraying equipment, helium mass spectrometer leak detector, spectrum analyzer, automatic ultrasonic flaw detector, X-ray detection machine, universal testing machine, impact testing machine and other sound sophisticated detection equipment.
Now the main products: cold tank car, tube trailer, tube bundle containers, gas cylinder with a group of stations, all types of cryogenic containers, a variety of CNG cylinders, automotive steel liner hoop wrapped natural gas compression bottles, large capacity seamless steel gas cylinders, large volume steel liner wrapped cylinders and so on.
Our company is one of the largest pressure vessel factories in China, with trademark "Luxi" as brand name. Our high quality products are widely used in China market, as well as oversea markets: Armenia, Colombia, Malaysia, India, Indonesia, Iran, Peru, Russia, Thailand, Uzbekistan, etc.
Along with the development of world natural gas industry, higher quality products will be offered to customer from worldwide.
