XQ328 yarn making twisting machine
USD $20,000 - $25,000
/ Set
1 Set(Min.Order)
- 500 Set / Sets per Month
- Ning Bo OR Shang Hai
You May Like
Product Details
Condition: | New | Type: | Other, Chemical Fiber | Place of Origin: | Zhejiang, China |
Brand Name: | XIANQU | Model Number: | XQ328F | Voltage: | 380V |
Power(W): | 13kw | Dimension(L*W*H): | 20300*770*1800mm | Certification: | ISO9001:2008 |
Warranty: | One Year | After-sales Service Provided: | Overseas third-party support available |
Product Description
Features:
1.A reasonable stored height, more fitted for Chinese female workers.
2.An improvement based on equipment G,E, economical and more practical yarn quality.
3.Absorbed advanced Italian, German and Japanese technologies, so the yarn route temperature
is more reliable along with a still better yarn quality.
Technical Specification
Number of Spindles | 128 Spindles As Basic Number(16 Multiplication and so on) | Type | Two Side,Single Layer |
Spindle Distance | 225mm | Spindle | Spindle Bell Wheel Diameter:Φ28 |
Spindle Speed | 9000-16000 rpm | Faise Twist Range | Motors for winding and spindles are separate. Theoretically the number of thrns are settable as one likes and intinitely regulatable |
Twis Direction | S or Z | Tension Control | Multi-sectional tension ball and tensiong ring are jointly put in use. |
Maximum Winding Capacity | Φ160*152 | Applicability | 50D-400D Polyester & Chemical Fiber Filament Yarns |
Unwinding Spool Specification | Φ110*Φ42*270-290 | Max.Speed of the false twister rotor | 260000RPM |
Electro-Thermal Power | 10.5kw | Thermal Box Yarn-Pass Length | 400mm |
Overall size | 20300*770*1800MM | Winding Angle | Regulatable at will |
