TEXTILE MATERIAL PROCESSING FEEDING CHUTE MACHINE
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Spinning Production Line
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao /shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Cotton Blowing and Carding Machine in Spinning MachineUS$ 10,000 - 100,000MOQ: 1 Set -
Economical Cottton Carding With Feeding ChuteUS$ 10,000 - 100,000MOQ: 1 Set
-
Additive Licker-in Carding MachineUS$ 10,000 - 100,000MOQ: 1 Set
-
Patented A186G Carding MachineUS$ 10,000 - 100,000MOQ: 1 Set
-
Cotton Used A186G Carding MachineUS$ 10,000 - 100,000MOQ: 1 Set
Condition
New
Type
Spinning Production Line
Place of Origin
Shandong, China
Brand Name
gonovo
Model Number
FB
Spinning Method
Other, cotton carding
Specifications
1 touchable display screen2 autolevller
3 alloy steel rolling
min order 1, delivery time : 15 day
1. MACHINE TECHINIAL FEAURES:
|
Suitable materials |
Natural or man-made fibers less than 76mm |
Working width |
950mm |
kg/h Output |
100 (Max) |
Feed roller diameter |
φ120 |
Opening roller diameter |
φ250 |
rpm Fan speed |
2840 |
Exhaust air |
600-500 |
Installed power |
1.52kw |
|
W x T x H Shape dimension |
1414×600×3300mm |
Aligned with carding machines (A186F, A186G,FB201B, FA231 etc.) and blowing machines, this feeder can form a simple blowing and carding production line.
Main Structure see below:
Main features:
- Good open effection , less fiber damage.
- Feed rollers made of steel to ensure uniform cotton falling.
- Double feed rollers to keep fibers from winding rollers
- Feed rollers controlled by inverter.
- Machine equipped with protection device.
- Continuously and evenly control of down chute pressure to achieve a uniform sliver output
- Efficient improvement of sliver’s uniformity and weight.
- Draft ratio of output rollers can be selected according to raw materials to insure a stable sliver.
