Specifications
Single spindle driven: low power consumption and more flexible operation. Low noise. Less space. Better yarn quality.
Item |
Specification parameter |
Machine type |
Double face and single layer |
Application range (Tex) |
5×2~74×2 |
Suitable fibers |
cotton, acrylic fiber, polyester and blends |
Spindle pitch (mm) |
Cotton 225, wool 265 |
Spindle number/group |
16 |
Standard (max) spindle number |
128 (240) |
Spindle speed (max, rpm) |
Cotton 15000, wool 10000 |
Twist range (T/m) |
90-2800 |
Twisting direction |
S & Z twist interchangeable |
Feed package |
Cotton 152×φ140, Wool 152×φ160 |
Winding bobbin |
3°30’~5°57’ conical, parallel bobbin |
Winding package (max,mm) |
152×φ300 |
Changeable winding angle |
16°30’, 19° ,21°30’ |
Winding tension |
Adjusted by super feed roll |
Spindle drive way |
Single spindle drive |
Change Spindle speed way |
Frequency control speed |
Spindle brake way |
Electrical drive |
Piecing way |
Pneumatic piecing |
Tensioner shape |
Capsule |
Motors |
1 single spindle motor per spindle, 1 winding and traverse motors per set |
Installed power (KW) |
22 (0.16kw/spindle, traverse and winding 1.5kw) |
Execllent yarn qulaity. The CV value varies between 1.5%-3.1%
Every spindle is pre-set and tested. Customers only need align the machines and connect them, which greatly reduces the installation time.
Each spindle is driven by its own motor, which saves a lot of power by:
1. no belt friction
2. spindle can start and stop on its own.
3. The actual power comsumption is lower than the belt-driven machine.
The NOVO twister can run at a high speed without changing the spindle plate size, which increase the production capacity.
PAC control ensures user-friendly operation and more accurate control of the machine.
Good packing ensures safe gooding during the transportation.
NOVO twister is the best TFO twister in the
world!!!
