Specifications
Single spindle driven: low power consumption and more flexible operation. Low noise. Less space. Better yarn quality.Item |
Specification parameter |
Machine type |
Double face and single layer |
Application range (Tex) |
5×2~74×2 |
Suitable fibers |
cotton, acrylic fiber, polyester and blends |
Spindle pitch (mm) |
Cotton 225, wool 265 |
Spindle number/group |
16 |
Standard (max) spindle number |
128 (240) |
Spindle speed (max, rpm) |
Cotton 15000, wool 10000 |
Twist range (T/m) |
90-2800 |
Twisting direction |
S & Z twist interchangeable |
Feed package |
Cotton 152×φ140, Wool 152×φ160 |
Winding bobbin |
3°30’~5°57’ conical, parallel bobbin |
Winding package (max,mm) |
152×φ300 |
Changeable winding angle |
16°30’, 19° ,21°30’ |
Winding tension |
Adjusted by super feed roll |
Spindle drive way |
Single spindle drive |
Change Spindle speed way |
Frequency control speed |
Spindle brake way |
Electrical drive |
Piecing way |
Pneumatic piecing |
Tensioner shape |
Capsule |
Motors |
1 single spindle motor per spindle, 1 winding and traverse motors per set |
Installed power (KW) |
22 (0.16kw/spindle, traverse and winding 1.5kw) |
Execllent yarn qulaity. The CV value varies between 1.5%-3.1%
Every spindle is pre-set and tested. Customers only need align the machines and connect them, which greatly reduces the installation time.
Each spindle is driven by its own motor, which saves a lot of power by:
1. no belt friction
2. spindle can start and stop on its own.
PAC control ensures user-friendly operation and more accurate control of the machine.
Stardard packing to make sure the machines are safe in the transportation.
The Advantages of NOVO TFO twister are:
1. Single spindle control. This could reduce the deviation value betweeen spindles by 10 times, control the twisting unevenness efficiently and improve the consistency of the equipment.
2. The machine can run at max speed 15000RPM without changing any size of the spindle plate. You can save time and increase production.
3. Speed variation between every spindle is the smallest in the world; it is better than other European brand. Please see the test result chart in our catalogue, tested by textile association.
4. One worker can run more than 10 -20 sets machine at one time. To save a lot of labor cost.
5. Novo twister can save 20%-30% power compared the other brand twister. To help you save cost and gain more profit!
6. Alarm when no twist on the yarn and automatic stop single spindle without any power waste!
7. Memory of all the parameters. Don’t to worry about power lack and emergency stop. You can start normal production as soon as possible!
8. The length control and record for each spindle, you can set according to your needs.
9. The production can be recorded in single spindle and also in working shift. Easy for your management and analysis.
10. Different processes can be realized one single set of machine because each spindle can twister different yarn at the same time.
11. Untouched photocell detection of the yarn break, which can avoid damaging the yarn.
12. PAC control of the machine which is more advanced than the normal PLC or other control. We use WINCE system.
13. Remote control and maintenance and upgrade online, it is easy to supply additional after sale service and technical advice, software update.
14. The best yarn quality and uniform in every spindle in the world.
15. You don’t need to change gear and any apron belt frequently; you can save a lot of cost and labor.
NOVO TFO twister is the best TFO twister in the world!!!
