Kisstone long life coal mining grizzly sand vibrating feeder

Name: Kisstone long life coal mining grizzly sand vibrating feeder
Brand: KISSTONE
Availability: InStock

FOB Price

USD $26,000 - $150,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port FOB GUANGZHOU
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Ore
Power Type	Electric	Capacity(t/h)	200-550 t/h
Place of Origin	Guangdong, China	Brand Name	KISSTONE
Model Number	GZB1245B	Power(W)	18.5 KW
Dimension(LWH)	1200*4500mm	Weight	5.0t
Certification	CE, ISO, IAF, CNAB	Warranty	12 Months
After-sales Service Provided	Overseas service center available

Product Description

Kisstone long life coal mining grizzly sand vibrating feeder

The GZB series vibrating feeder is a slanting fitted vibrating feeder with single-mass elastic system. The electromotor makes the eccentric shaft and the eccentric mass and the eccentric mass of the vibrator produce enough excited force after being decelerated by the belt pulley, stimulating the machine case produce circular vibration with certain amplitude. The materials conduct continuous casting on the slant working surface with the excited force effect and move down during the casting process, realizing even feeding.This machines has simple structure, convenient operation, reliable working and easy maintenance, which is mainly used as the feeding machine in the departments like beneficiation, construction material, electricity, chemistry and so on. This machine has two types: plate type and bar type, which are separately marked as GZBXXXX and GZBXXXXB.

Model	Size of material surface (length x height)	Effective working area m2	Tilt angle of feeding material surface	Vibration frequency r/min	Double amplitude of case mm	Maximum feeding size mm	Processing capacity t/h	motor
Model	Size of material surface (length x height)	Effective working area m2	Tilt angle of feeding material surface	Vibration frequency r/min	Double amplitude of case mm	Maximum feeding size mm	Processing capacity t/h	Model	Power kw
GZB0715	700*1500	1.1	15-20	800	7-10	420	50-200	Y132M-4	7.5
GZB1017	1000*1700	1.7	15-20	800	7-10	600	80-320	Y132M-4	7.5
GZB1218	1200*1800	2.2	15-20	800	7-10	750	120-400	Y160M-4	11
GZB0730B	700*3000	2.1	15-20	700	7-10	750	120-450	Y180M-4	18.5
GZB0930B	900*3000	2.7	15-20	700	7-10	750	120-450	Y180M-4	18.5
GZB1035B	1000*3500	3.5	15-20	700	7-10	750	120-450	Y180M-4	18.5
GZB1045B	1000*4500	4.5	15-20	700	7-10	750	180-500	Y180M-4	18.5
GZB1235B	1200*3500	4.2	15-20	700	7-10	750	180-500	Y180M-4	18.5
GZB1245B	1200*4500	5.4	15-20	700	7-10	750	200-550	Y180M-4	18.5
GZB1250B	1200*5000	6.0	15-20	700	7-10	750	230-600	Y180L-4	22
GZB1560B	1500*6000	9.0	15-20	700	7-10	900	280-700	Y225S-4	37

1. Simple structure, easy to install and use, stable performance

2. Easy to adjust, low maintenance cost

3. Reliable operation, low noise

4. High efficiency and feeding capacity

5. No pollution with closed body, and long service life
