1.5"~24" PN10/16 Water Seal Butterfly Valve

US$ 8 - 40,000 MOQ: 1 Set

Key Specifications

Standard or Nonstandard:

Standard

Structure:

Butterfly

Pressure:

Low Pressure

Tianjin Tanggu Water-Seal Valve Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Standard or Nonstandard Standard

Structure Butterfly

Pressure Low Pressure

Power Manual

Material Casting

Temperature of Media Medium Temperature

Media Water

Port Size DN50~DN600

Place of Origin Tianjin, China

Model Number Series

Brand Name TWS

One Piece Stem Wafer Butterfly Valve Without Pin:

1.5"~24" PN10/16
Flange: ANSI B 16.1, EN 1092, AS 2129
F/F: ANSI B 16.10

Brief Introduction:

Butterfly valve is mainly consisted of body, stem, disc, seat and driver(lever, gearbox, pneumatic and electric Actuator) and so on. On off and

controlling flow of valve are made by turning stem and disc together.

Detail Specification:

Lever operated one piece stem wafer butterfly valve without pin:

Size	DN40-DN600
End flange	ANSI B 16.1, EN 1092, AS 2129
Face to face	ANSI B 16.10
Top flange	ISO 5211
Normal pressure	DN40-DN600 PN1.0/1.6MPa (150/200PSI)
Body	CI/DI/WCB/ALB/CF8/CF8M
Disc	DI/ALB/Rubber lined Disc/ 1.2501/CF8M/1.4529/CF8/Hastelloy
Stem	416/304/316/431/17-4PH
Seat	NR/Hypalon/EPDM/Neoprene/NBR/Wear-Resistant EPDM/Viton/Silicon/Heat-Resistant EPDM/White NBR/White EPDM/EPDM (NSF)/PTFE
Taper pin	416/316/431/17-4PH
Bushing	Lubrized Bronze/PTFE
O-Ring	NBR/EPDM
Key	45 1045
Bearing	Bearing steel
End Cover	CI/WCB/CF8/CF8M
Bolt	Q235 Gr.33 35 1035 / 304
HEX Screw	Q235 Gr.33
Temperature	-45c~150c
Feature	Small in size, light in weight and easy maintenance, it can be used as a device to cut-off or regulate
O-Ring
Apply	Fresh water, sewage, sea water, air, vapor, food, medicine, oils. acids, alkalis, salt etc.
