Help CenterBellows Seal Control Valve
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Control
Pressure:
Low Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pneumatic Single Seat Control ValveNegotiableMOQ: 2 Sets -
HTS Pneumatic Single Seat RegulatorNegotiableMOQ: 2 Sets
-
Stainless Steel Single Seat Control ValveNegotiableMOQ: 1 Set
-
Self Actuated Control ValveUS$ 1,000 - 1,000MOQ: 2 Sets
-
Electric Single Seat Control ValveUS$ 1,000 - 1,000MOQ: 2 Sets
Standard or Nonstandard
Standard
Structure
Control
Pressure
Low Pressure
Power
Pneumatic
Material
Casting
Temperature of Media
Medium Temperature
Media
Gas
Place of Origin
Jiangsu, China
Model Number
HTSW
Brand Name
CEPAI
Technical specifications
| Body type: | Cage type control valve |
| Size: | DN15~DN250 (3/4" to 10") |
| Pressure Class: | PN16,PN40,PN64 |
| ANSI 150,ANSI300,ANSI600 | |
| Characteristics: | Equal Percentage, Linear, quick open |
| Body Materials: | WCB, LCB, CF8M, |
| CF3M | |
| Trim materials: | 304, 316, 304L, 316L |
| Temp range: | -196°C to +566°C |
| Connection: | Flanged, Socket welding, Butt welding |
| Gland packing: | PTFE, Braided PTFE, Grafoil |
| Leakage: | Class IV (Metal seat, standard), Class V, |
| Class VI (Soft seat, zero leakage) | |
| Actuator: | Pneumatic diaphragm actuator, Piston |
| Positioner: | High Performance Smart positioner (Explosive |
| proof and HART Protocol are available) |
