Help CenterMotorized Control Valves
US$ 1,000 - 1,000
MOQ: 2 Sets
Key Specifications
Get Latest Price
Standard or Nonstandard:
Other, design
Structure:
Control
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Other, design
Structure
Control
Pressure
Medium Pressure
Power
Other, Electric
Material
Casting
Temperature of Media
Medium Temperature
Media
Gas
Port Size
1/8" 1/4" 3/8" 1/2"
Place of Origin
Jiangsu, China
Model Number
EDTS
Brand Name
CEPAI & OEM
Application
Other, Chemical
Packaging & Shipping
Technical specifications
| Body type: | Cage guided, globe control valve type |
| Size: | DN15~DN250 (3/4" to 10") |
| Pressure Class: | PN16,PN40,PN64 |
| ANSI 150,ANSI300,ANSI600 | |
| Characteristics: | Equal Percentage, Linear, quick open |
| Body Materials: | ZG230~450, ZG1Cr18Ni9, WCB, LCB, CF8M, |
| CF3M | |
| Trim materials: | 304, 316, 304L, 316L |
| Temp range: | -196°C to +566°C |
| Connection: | Flanged, Socket welding, Butt welding |
| Gland packing: | PTFE, Braided PTFE, Grafoil |
| Leakage: | Class IV (Metal seat, standard), Class V, |
| Class VI (Soft seat, zero leakage |
Product Description
CEPAI Pneumatic single seat control valve is a top entry globe type control valve, which is manufactured under ISO 9001 quality
assurance system. The body channel is streamlined by S shape with low pressure loss, high capacity, wide regulating range, and high accuracy in flow characteristics. The plug features with guiding area and good vibration resistance. The control valve is
equipped with mult-spring diaphragm actuator and compact in structure as well as big in output force. This valve is designed to
control a broad variety of fluids, like steam, water, most of the medium and gases.
