Stainless Steel Spool Wire/stainless Steel Coil Wire

FOB Price

US$ 2 - 100 / Kilogram

100 Kilograms(Min. Order)

Port xingang
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Standard	AISI, ASTM	Grade	Other, 200 300 400 Series
Wire Gauge	0.018-6.0mm	Length	any
Application	spring, screw, rope, steel brush, pin,mesh, jewelry	Certification	ISO
C Content (%)	≤0.15	Si Content (%)	≤1.0
Place of Origin	Hebei, China	Brand Name	DCL
Model Number	006

Product Description

Stainless steel wire

1. Austenitic stainless steel:
304, ( 06Cr19Ni10)
304L, ( 00Cr19Ni10 )
316L, ( 00Cr17Ni14Mo2 )
316 contain molybdenum 304 neither molybdenum nor titanium, 316L is the best.
2. Specification:
1)material: 3 series common ss304 ss304l ss316 ss316l
2)diamater: 0.02-5.0mm
3)tensile strength: 520Mpa-1800Mpa
4). Surface: Light or dull
5). Package: (1)spool---HDPE bags---paper box
(2)coil---HDPE bags---weave or hessian bags outside

AISI	C	SI	MN	P	S	NI	CR	MO	TENSION	ELONGATION
302	≤0.15	≤1.0	≤2.0	≤0.045	≤0.03	8-10	17-19		750-850Mpa	≥35%
304	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	8-10.5	18-20		750-850Mpa	≥35%
304L	≤0.03	≤1.0	≤2.0	≤0.045	≤0.03	8-10	18-20		750-850Mpa	≥35%
316	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	10-14	16-18	2.0-3.0		≥35%
316L	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	12-15	16-18	2.0-3.0		≥35%
321	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	8-11	17-19			≥35%

Specification:

Wire Diameter(mm)	Specification
Wire Diameter(mm)	Tolerance(mm)	Max.Deviation Tolerance(mm)
0.020-0.049	+0.002;-0.001	0.001
0.050-0.074	+0.002;-0.002	0.002
0.075-0.089	+0.002;-0.002	0.002
0.090-0.109	+0.002;-0.002	0.002
0.110-0.169	+0.003;-0.003	0.003
0.170-0.184	+0.004;-0.004	0.004
0.185-0.199	+0.004;-0.004	0.004
0.200-0.299	+0.005;-0.005	0.005
0.300-0.319	+0.006;-0.006	0.006
0.320-0.499	+0.006;-0.006	0.006

Wire Reels For Stainless Steel Wire
Reel Type	D	d	L	W	A	H	Reel Weight	Wire Weight Per Reel
DIN100	100	63	100	80	10	16	0.12	1.0
DIN125	125	80	124	100	12	20.6	0.20	3.5
DIN160	160	100	159	127	16	22	0.48	5
DIN200	200	125	200	160	20	22	0.60	10
DIN250	250	160	200	160	20	22	1.24	20
P3C	119	54	149	129	10	20.6	0.20	4.5
PL3	120	76	150	130	10	20.6	0.20	3.5
NP2	100	60	129	110	9.5	20.6	0.12	2.5
PL1	80	50	120	100	10	20	0.08	1.0
P1	100	50	90	70	10	20	0.10	1.0

3. Commom specification:
1)s soft: Surface light, soft, non-magnetic, anti-fatigue, extension strength, etc, Wire diameter: 0.03-5.0mm. Material: 301, 302, 304, 304L, 316, 316L, 310, 310S, 321
2)LD, lightly drawn: Steel wire after heat treatment, decrease for small drawing below. Surface light, soft, anti-fatigue, have certain extension force, etc. Wire diameter: 0.03-5.0mm Material: 301, 302, 304, 304L, 316, 316L, 310, 310S, 321
3)WCD, cold drawn: Smooth surface, good toughness and wear resistance. Wire daimeter: 0.03-6.0mm Material: 302, 304, 304L, 316, 316L, 310, 310S, 321
4)Stainless steel spring wire:
High hardness, elasticity, abrasion resistance performance is good. Wire diameter: 0.15-3.0mm Material: 302, 304H, 304L, 316, 316L, 310, 310S, 321

4. Product Application:
With bright surface, slight magnetism and no cracks on forming, is widely used in bicycle fittings, kitchen and sanitation tools, goods shelf, pet cages, gill racks, decorative handles and baskets, food and medical machinery accesses, etc.
5. Our advantage:
Our range of Wire made of Stainless Steel are not only known for their variety but are also known for their good quality, long life and very reasonable prices. Quality and service is our first priority, we effectively use technically advanced machinery equipment and the expertise of our work to deliver our stainless steel wired
6. Loading Port: Tianjin xin gang port
7. Delivery lead time: 10 working days after received deposit.
8...Payment term: 30% by T/T as deposit., balance will be paid by T/T,
9. Quality assurance: Mill Test Certificate is supplied with shipment, third Party Inspection is acceptable
10. Note: The price is just reference, the latest price please directly contact me.
