Multi-functions All in One Screw Plant Seed Oil Press

Name: Multi-functions All in One Screw Plant Seed Oil Press
Brand: GUANGXIN
SKU: 132659303
Availability: InStock

US$ 3,000 - 4,000 MOQ: 1 Piece

Key Specifications

Condition:

New

Usage:

Peanut Oil

Type:

Other, Cold & Hot Pressing Machine

Mianyang Guangxin Machinery Of Grain & Oil Processing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Chongqing Guangzhou Shanghai or any other China port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Usage Peanut Oil

Type Other, Cold & Hot Pressing Machine

Automatic Grade Automatic

Production Capacity 1.0 ton/24hours

Place of Origin Sichuan, China

Brand Name GUANGXIN

Model Number YZYX70ZWY

Voltage 380V

Power(W) 4k.W

Dimension(L*W*H) 1218*1160*1882mm

Weight 650kgs

Certification ISO, BV

After-sales Service Provided Engineers available to service machinery overseas

Specifications

all in one screw plant seed oil press
-with heater, fryer, squeezer and filter
-mini, easy operating, make oil from seeds

1. YZYX70ZWY Characteristics

Has combined functions in one—auto warming up, frying, squeezing and crude oil's filtrating, therefore saves labor cost and time consumption. Users no need to buy a frier for hot pressing.
The function of auto-heating the press cage has replaced the traditional way by squeezing residue cake, which shortened the preparation work and reduced the energy consumption. When the squeezing is suspended, the temperature can be maintained at a certain degree by this system.
The two vacuum filters equipped on the machine has advantages of easy operating, high output and the filtration result is precise.
Day output 1.0 ton/24h, oil content of residue cake is ≤8%.
Healthy! Physical squeezing craft maximally keeps the nutrients such as the protein, fatty acids and minerals, etc.
High working efficiency! The spiral squeezing structure can achieve high oil output, the oil content of the residue cake is low. Oil plants only need to be squeezed by one time when using hot pressing.
Long durability! Long durability: all the parts are made of the most suitable material and treated with refined crafts, such as cemented quenching and tempering to increase the hardness, consequently the durability.
Cost-effective! The wearing parts on the machine such as the squeeze loop, squeeze spiral and squeeze bar are designed to be dismountable. When they are out of service period, users only need to replace them and no need to displace the whole machine.

Model	YZYX70ZWY
Processing capacity (t/24h)	1.0
Oil content of dry cakes (%)	≤8
Squeezing power (k.W)	4
Frying power(k.W)	6
Filter power(k.W)	0.55
Temperature control power(k.W)	1.2
Mixing power(k.W)	0.25
Measurement (mm)	1218×1160×1882
Spiral axes rotate speed (r/min)	32-42
Weight (KG)	650

2. YZYX70ZWY Suitable oil material type and business type.

More than 30 kinds of oil material, such as rapeseeds, cotton seeds, soybean, shelled peanut, flax seeds, sunflower seeds and palm kernel, etc. Especially for making refined high class plant oil.
Medium and small oil refinery, oil mill. Especially good for processing materials supplied by clients .
