MDA2000 is composed of lighting system, optics system, sensor-IC system and software, including parts of standing base, focusing wheel, digital module cabin, USB cable, and software CD.
When linking with PC and controlling by software many excellent jobs will be done, including tiny target search, display, shoot, movie, measure, compare and edit, and just function as composition of microscope, digital camera, digital video recorder, projector, scanner, micro-ruler and PC camera.
MDA2000 has wide applications in industry, education, research, health, and family life.
Advantage:
1. One set of conjugation lenses offer two different magnification, low magnification is for wide view and high magnification for detailed inspection.
2. Advanced sensor and IC module design provides wide dynamic range and true cell color expression.
3. Equipped powerful software is multi-functional on image processing: shoot, video record,measurement, edit..
4. Software is compatible for different windows operating system and have 7 different language vision to meet customers' requirement.
5. Product and software has patent, and receives CE FC RoHS certificate.
Certification:
CE issued by SGS laboratory Verification No. SHEMO0808001971T01C
FC issued by SGS laboratory Verification No.SHEMO081100389IT01C
ROHS issued by POCE laboratory, Verification No.POCE13072325TCR
Copyright software of Future Win Joe V1.0 Registration Code: 2009SR035346
ISO9001-2008 issued by kunlun certification co., Ltd Verification No. 16814QZ0030R0M
OEM/ ODM:
Available for both hardware and software to be designed and made on clients' specification.
Including:
Logo package printing;
Optical system design;
PCB imaging module design;
Shell design ;
Software amendment.
Detail Specifications:
Capture Mode | Picture and Video |
Sensor Parameter | 1/2” 2.0MP Color CMOS |
Max. Resolution | 1600*1200 |
Pixel Size | 4.2 µm x 4.2 µm |
Sensitivity | 1.0 V/Lux-sec |
Dynamic Range | 60 dB |
S/N Ratio | 54 dB |
Working Distance | 5.0MM ---∞ |
Magnification | 40X; 240X |
Spectral Range | 400-650nm(with IR-filter) |
Frame Rate | 10fps@1600*1200 |
Preview Model | 640x480,320x240 |
Exposure | ERS or Manual |
Power Consumption. | 170mw |
White Balance | Auto and Manual |
Device Weight | 0.12kg |
Device Size | Φ45mm*95mm |
Out Interface | USB2.0 |
Function of Software | Image & video Capture, Edit and Management |
System Compatibility | 32bit and 64bit XP, Vista, Win7,Win8,MAC |
Language of software | English, French, German, Spanish, Japanese, Chinese, Russian |
PC Requirements | CPU: Inter Core2, 2.8GHz or Higher; Memory: 2GBor More; USB Port:USB2.0 High-speed Port |
Trade terms
Payment:
100% prepaid for first order
For quantity order: T/T to our company account
For sample order or trial order: T/T to our company account, Western Union, Escrow
Delivery time and shipping:
Sample order or trial order (less than MOQ) will be sent within 3 days by express, such as EMS, DHL, TNT, FedEx etc.
Bulk order (less than 500 units) will be finished within 7 days, and normally shipped by air or sea through forwarders subject to client’s confirmation.
OEM orders need an extra customization time. Generally customization will take 10 days.
Warranty:
We offer two years warranty covering all of our products, including on line technical supports, replacements of defective items with new ones and supply of accessories, basing on our service offices all over the world.
Customization:
We offer free OEM service for our regular clients or big order customers, including logo printing, sticker print, CD file design and box making .--------------more information
Free sample for clients to place repeat orders:
We welcome our potential buyers to purchase sample for test and evaluation, and we will refund the sample fee when they place repeat orders.
Pre-sales service
As a manufacturer, not a trade company, we can provide sufficient pre-sale services to help our clients understand our products before placing an order to us.
1. Provide basic knowledge to help our clients understand working principle of our products;
2. Provide key factors and skill to our clients when they choose our products;
3. Provide sample pictures or video captured by our products according to clients’ special application for test and evaluation;
4. Provide product design drawing and package drawing to help clients work out customization pattern.
