Home > Instruments & Meters > Optical Lens & Instrument > Microscope > Easy Operation 1.3MP Handheld USB Digital Microscope for Skin Checking

Easy Operation 1.3MP Handheld USB Digital Microscope for Skin Checking

Hangzhou Future Optics Sci & Tech Co., Ltd.

Easy Operation 1.3MP Handheld USB Digital Microscope for Skin Checking photo-1

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

OEM

Model Number:

MDA1300

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name OEM

Model Number MDA1300

Theory Other, Optical Sensor

MDA1300 is composed of lighting system, optics system, sensor-IC system and software, including parts of standing base, focusing wheel, digital module cabin, USB cable, and software CD. When linking with PC and controlling by software many excellent jobs will be done, including tiny target search, display, shoot, movie, measure, compare and edit, and just function as composition of microscope, digital camera, digital video recorder, projector, scanner, micro-ruler and PC camera. MDA1300 has wide applications in industry, education, research, health, and family life.

Advantage

1. The conjugation of optical system offers two different magnifications with single set of lens.

2. Built in 8 LED light ring with special parameters and special position located ensures the uniform field in illumination.

3. Advanced design of sensor and IC module offers wide dynamic range and true color expression.

4. The special design of optics system enables MDA Series has a long work distance of microscope and makes it possible to act as a tool in assembly.

5. UVC for use in Windows XP, Vista makes the installation easy and convenient

6.Eight language versions of software for selection

Features

Low magnification	1X---40X
High magnification	200X
Working distance	5.00 mm---∞
Lighting source	8 LED light ring
Focusing	Hand-wheel and twin screw track
Function of software	Image management: to set up, to open up, to save, and to lead in image file Image capture: to switch, to set, to shoot, to video. Image edit: picture turn, zoom, cut, modify, email, print
Resolution of display	1280*1024
Resolution of picture	1280*1024
Resolution of video	1280*1024
USB cable	1.5 m
Weight of device	0.12kg

Specifications

Sensor parameter	1/4 1.3Mega Pixels CMOS
Active Pixels	1280*1024
USB port	USB 2.0
Frame Rate	16 f/s @ 1280*1024
Preview Model	12801024,640480, 320*240,
Dynamic Range	71dB
Sensitivity	1.0V/lux-sec@550nm
Spectrum response	400nm---1000nm
Shutter Type	ERS(electronic rolling shutter)
White Balance	Auto
Operating System	Windows XP, Vista

Trade information

Trade terms

Payment:

100% prepaid for first order

For quantity order: T/T to our company account

For sample order or trial order: T/T to our company account, Western Union, Escrow

Delivery time and shipping:

Sample order or trial order (less than MOQ) will be sent within 3 days by express, such as EMS, DHL, TNT, FedEx etc.

Bulk order (less than 500 units) will be finished within 7 days, and normally shipped by air or sea through forwarders subject to client’s confirmation.

OEM orders need an extra customization time. Generally customization will take 10 days.

Warranty:

We offer two years warranty covering all of our products, including on line technical supports, replacements of defective items with new ones and supply of accessories, basing on our service offices all over the world.

Customization:

We offer free OEM service for our regular clients or big order customers, including logo printing, sticker print, CD file design and box making .--------------more information

Free sample for clients to place repeat orders:

We welcome our potential buyers to purchase sample for test and evaluation, and we will refund the sample fee when they place repeat orders.

Pre-sales service

As a manufacturer, not a trade company, we can provide sufficient pre-sale services to help our clients understand our products before placing an order to us.

1. Provide basic knowledge to help our clients understand working principle of our products;

2. Provide key factors and skill to our clients when they choose our products;

3. Provide sample pictures or video captured by our products according to clients’ special application for test and evaluation;

4. Provide product design drawing and package drawing to help clients work out customization pattern.
