- Variable wire speed range from 0-40M/Sec, allows to quarrying all kinds of stone material with different hardness and texture like marble, granite, sandstone etc.
- Automatic constant tensioning system to keep the wire always in optimal working condition and furthest guarantee the cutting duration of diamond wire.
- Angle adjustment range from 0-360 degree(electric auto), allows to horizontal, vertical and any direction cutting.
- Horizontal extention system of flywheel shaft position range from 350-400mm(electric auto).
- Quick Backward speed of machine without loading range from 1750mm/Min.
- Separate control panel with feature of easy and safe manipulation for operator.
- Safety stop in case of unexpected wire breakage or other faults.
Specifications of Travertine rope saw machine:
Model |
Main Motor |
Length of wire (Meter) |
Linear Speed (M/Sec) |
Diameter of driving wheels (mm) |
Application |
LQ-WSM-11KW |
11KW/15HP |
5-20 |
0-40 |
Φ550 |
For block trimming |
LQ-WSM-15KW |
15KW/20HP |
5-30 |
0-40 |
Φ550 |
|
LQ-WSM-22KW |
22KW/30HP |
10-40 |
0-40 |
Φ600 |
|
LQ-WSM-37KW |
37KW/50HP |
20-80 |
0-40 |
Φ800 |
For Quarry |
LQ-WSM-45KW |
45KW/60HP |
20-100 |
|||
LQ-WSM-55KW |
55KW/750HP |
20-120 |
|||
LQ-WSM-75KW |
75KW/100HP |
20-150 |
0-40 |
Φ1000 |
Remarks:
1.Schneider or Siemens inverters is available as per customer's requirements.
2.Standard power supply is 3-phases, 380Volts, 50Hz, other types could be ordered by customer.
3.We are in a position to design the Wire Saw Machines as per customer special requirement.
Packaging: All packing will be done with protection against damages while transporting.
Delivery time: In 7 days for one set of wire saw machine.
1. Wire sawing operational assistance service.
2. Proposal for quarry development and plan, if necessary.
(Photos of Travertine rope saw machine):
arry Wire
We, KEEN TOOL is a specialized manufacturer of diamond tools for construction industry.
KEENTOOL will be best solution for customers in fields as below:
- Diamond Wire for stone quarry, blocks trimming and profiling.
- Diamond Wire for controlled demolition work of construction with structure of concrete, reinforced concrete and steel.
- Wire Saw Machine with variable speed and step-less tension system for quarry and block cutting.
- DTH drills with complete Pneumatic system, or Pneumatic & Electrical system for drilling the wire hole.
- Conventional Diamond Tools for processing stone and other construction materials.
Welcome to visit our website of or https://img13.fr-trading.comto know more about us.
Saw Machine
