South Africa black heavy duty pvc pipe 4 inches
- 1000 Ton / Tons per Month
- qingdao lianyungang Rizhao
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Dongli | |
| Model Number | PVC pipe | Material | PVC | |
| Specification | DN20-DN800mm | Length | 5.8m,11.8m or at request | |
| Thickness | 2.0-30.6mm | Standard | GB/T10002.1-2006,DIN,ASTM |
Product Description
South Africa black heavy duty pvc pipe 4 inches
Dn,mm |
| |||||||
0.63mpa | 0.8mpa | 1.0mpa | 1.25mpa | 1.6mpa | 2.0mpa | 2.5mpa | ||
20 | - | - | - | - | - | 2.0 | 2.3 | |
25 | - | - | - | - | 2.0 | 2.3 | 2.8 | |
32 | - | - | - | 2.0 | 2.4 | 2.9 | 3.6 | |
40 | - |
| 2.0 | 2.4 | 3.0 | 3.7 | 4.5 | |
50 | - | 2.0 | 2.4 | 3.0 | 3.7 | 4.6 | 5.6 | |
63 | 2.0 | 2.5 | 3.0 | 3.8 | 4.7 | 5.8 | 7.1 | |
75 | 2.3 | 2.9 | 3.6 | 4.5 | 5.6 | 6.9 | 8.4 | |
90 | 2.8 | 3.5 | 4.3 | 5.4 | 6.7 | 8.2 | 10.1 | |
110 | 2.7 | 3.4 | 4.2 | 5.3 | 6.6 | 8.1 | 10.0 | |
125 | 3.1 | 3.9 | 4.8 | 6.0 | 7.4 | 9.2 | 11.4 | |
140 | 3.5 | 4.3 | 5.4 | 6.7 | 8.3 | 10.3 | 12.7 | |
160 | 4.0 | 4.9 | 6.2 | 7.7 | 9.5 | 11.8 | 14.6 | |
180 | 4.4 | 5.5 | 6.9 | 8.6 | 10.7 | 13.3 | 16.4 | |
200 | 4.9 | 6.2 | 7.7 | 9.6 | 11.9 | 14.7 | 18.2 | |
225 | 5.5 | 6.9 | 8.6 | 10.8 | 13.4 | 16.6 | - | |
250 | 6.2 | 7.7 | 9.6 | 11.9 | 14.8 | 18.4 | - | |
280 | 6.9 | 8.6 | 10.7 | 13.4 | 16.6 | 20.6 | - | |
315 | 7.7 | 9.7 | 12.1 | 15.0 | 18.7 | 23.2 | - | |
355 | 8.7 | 10.9 | 13.6 | 16.9 | 21.1 | 26.1 | - | |
400 | 9.8 | 12.3 | 15.3 | 19.1 | 23.7 | 29.4 | - | |
450 | 11.0 | 13.8 | 17.2 | 21.5 | 26.7 | 33.1 | - | |
500 | 12.3 | 15.3 | 19.1 | 23.9 | 29.7 | 36.8 | - | |
560 | 13.7 | 17.2 | 21.4 | 26.7 | - | - | - | |
630 | 15.4 | 19.3 | 24.1 | 30.0 | - | - | - | |
project | Indicators | |
Density,kg/m3 | 1350~1460 | |
Vicat softening temperature ℃ | >80 | |
Longitudinal reversion % | <5 | |
Methylene chloride immersion test 15℃,15min | Surface changes are not inferior to 4N | |
Drop hammer impact test (0℃) TIR,% | <5 | |
Hydraulic test | DN<40mm,20℃ 36mpa 1h | No rupture,no leakage |
DN>40mm,20℃ 36mpa 1h | ||
20℃ 30mpa 100h | ||
10℃ 60mpa 1000h | ||
System suitablity test | Links tightness test | |
Negative pressure test | ||
Declination test | ||
South Africa black heavy duty pvc pipe 4 inches
1.Raw material with uv resistance agent
2.centralized material supply system
3.Imported Advanced equipments:Dekemo molding machine
4.one production line with double moulding press,our productivity rate is three times of other common equipments.
5.one time moulding and socket-making in same production line,assures the pipes quality.
6.eco-friendly raw material assures the safety of pipes.
7.wide range choice from 16mm---800mm.
Thank you for your view of our products,
For detailed information,like pipe speficiation,test report,loading capacity and so on,please pressue" contact supplier" or click " Chat Now".
Jenny is always at your disposal.Also warmly welcome your visit to our factory at your time.
Jenny
Tel:008618953996016
skype:liu198425yan
QQ:201257803
Wechat:18953996016
whatsapp:18953996016
Address:Cross of ShenYang Road and KunMing Road,Linyi city,Shandong Province.
