Specifications of battery pullet rearing cage poultry equipment
1. Materia: Q235 National standard Low carbon steel wire mesh
2.Surface treatment: Electro galvanize or hot galvanize or plastic coating
3.Specialty: Easy to assemble. Feeding and easy management, save the space, effectively prevent infectious diseases, and increase the survival rate.
4.If there are special cage specifications, also can be customized
5.Full automatic equipments: automatic drinking system, automatic feeding system, automatic
manure removal system, automatic egg collection system etc.
Parameter Data for battery pullet rearing cage poultry equipment
Item No. |
Volume |
Cell dimension |
Bird /cell |
Weight |
Remarks |
Overall size |
ST3A90-5 doors |
90 layers |
390x390x390mm |
3 |
42kgs |
6 strips (30 cells) |
1950x2150x1620 |
ST3A96-4 doors |
96 layers |
487x400x400mm |
4 |
45kgs |
6 strips (24 cells) |
1950x2150x1650 |
ST3A120-5 doors |
120 layers |
390x500x400mm |
4 |
50kgs |
6 strips (30 cells) |
1950x2150x1650 |
ST4A120-5 doors |
120 layers |
390x390x390mm |
3 |
56kgs |
8 strips (40 cells) |
1950x2350x1720 |
ST4A128-4 doors |
128 layers |
487x400x400mm |
4 |
60kgs |
8 strips (32 cells) |
1950x2350x1750 |
ST4A160-5 doors |
160 layers |
390x500x400mm |
4 |
65kgs |
8 strips (40 cells) |
1950x2350x1750 |
ST5A150-5 doors |
150 layers |
390x390x390mm |
3 |
70 kgs |
10strips (50 cells) |
1950x2550x2120 |
ST5A160-4 doors |
160 layers |
487x400x400mm |
4 |
75 kgs |
10strips (40 cells) |
1950x2550x2250 |
ST5A200-5 doors |
200 layers |
390x500x400mm |
4 |
80 kgs |
10strips (50 cells) |
1950x2550x2250 |
1.Hot-dipped wire mesh cage, double ability in anti-rust and anti-corrosion.
2. Hot-dipped wire mesh cage can enjoy a 15-20 year life span, while cold
galvanized cage can withstand 7-10 years.
3. Hot-dipped steel plate cage leg support, not welded angle-iron steel bar with oil painted.
Note:
Using 5-tier cage, it will demand for automatic egg collecting system, as well as automatic feeding system, so the cost will be a little big, so people usually choose 4-tier, or 3-tier cage.
Diameter for wire mesh
1. 2.3mm Q235 steel wire (Egg Tray); if diameter thicker, the egg breaking rate rise by 1-2%.
2. 2.5mm Q235 steel wire (Cage Door)
3. 3.2mm Q235 steel wire (Cage Top)
Galvanization Time
Our electro-galvanizing time period: 30 minutes; Other factories 8-15 minutes;
Cage Frame:
Hot-dipped steel plate punched & formed one-time;
Neither 3x3 GB nor 4x4 GB angle-iron steel bar welded & painted frame
Surface treatment of wire mesh:
1. Electro-galvanization;
2. Galvanization & Plastic Coating;
3. Hot-dipped process
Optional System in the chicken house:
1. Manure Removal System;
2. Air Ventilation System
3. Automatic Feeding System
4. Egg Collection System
5. Heating System in house
Pre-sale service:
help you design the equipments layout. 2. take you see our factory. 3. answer all your question.
In-sale service: ensure the quality and delivery time.
After-sale service:
We supply videos and installation instruction to teach how to install the equipments.
We have been in the wire mesh business for over 15 years, so we have many years of experience to draw on.
We are continuing to grow through a very satisfied customer base, as well as new customers from the
Internet and referrals, our high quality of product and work is what sets us apart from the competition; Our goal is also to offer materials and workmanship that will last for years.
