Help CenterHD Satellite Receiver With CI Slot
Related Products
Specifications
DVB-S HD Satellite receiver with CI slot1,DVB-S tuner inputs
2,VBI TELETEX , SUBTITILE
3,Various choice of I/O interfaces
Features
Factory optional for DVB-S/-S2/-T/-C, ISDB-T tuner inputs
MPEG-2 (MP@ML&MP@HL) and MPEG-4 Part 10 ( AVC high profile level 4.1) standards complaint and decoding
Various choice of I/O interfaces, including ASI input/output, CVBS output, YPbPr output, HDMI output, SD/HD output (embedded 2 pairs stereos audio), AES/EBU output, 10/100M TS over IP input/output ( optional)
Built-in re-multiplexer ( temporarily unavailable )
VBI TELETEX , SUBTITILE support
Caption support
10/100M Ethernet TS over IP I/O, UDP protocol
Unicast and multicast support
Two DVB-CI slots, multiple programs decryption support
NMS control support
Specifications
NDS3912 DVB-S HD IRD |
Input Frequency Range: 950-2150MHz |
Symbol rate: 2-45MBauds |
Signal Strength: -65- -25dBm |
FEC Demodulation: 1/2, 2/3, 3/4, 5/6, 7/8 QPSK |
|
RF interface |
Input frequency |
950~2150MHz |
Input level |
-65~-25dBm |
|
Signal input type |
F interface |
|
Input impedance |
75 |
|
Symbol ratio |
1-45Msymbols |
|
Demodulation mode |
QPSK, 8PSK |
|
Frequency stepping |
500KHz |
|
|
Code rate |
DVB-S: 1/2, 2/3, 3/4, 5/6, 7/8 |
|
DVB-S2: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10 | ||
|
DVB-CI module |
Descrambling procession |
Supporting European DVB-CSA |
Smart Card interface |
ISO7816 |
|
Interface Card separation |
PCMCIA |
|
|
ASI interface |
BNC interface (with one input channel and 2 output channels) |
I/O impedance 75 |
Maximum transmitting rate |
416Mbps |
|
SDI interface |
Supporting SMPTE424M, SMPTE 292, SMPTE 259M-C and DVB-ASI Supporting 1080i 50/60 4:2:2 10-bit |
Maximum transmitting rate 1.485 Gb/s |
USB |
Supporting USB1.1 and USB2.0 |
Transmitting rate 1.5Mb/S,12Mb/S and 480Mb/S |
RJ45 |
Supporting IEEE 802.3 |
10Mb/100Mb |
|
CVBS |
Video output amplitude |
700±30mVP-P |
Video synchronous Amplitude |
300±20mVP-P |
|
|
Video amplitude frequency features
|
±0.8 dB ( within 4.8MHz) ±1 dB ( 4.8-5MHz ) +0.5/-4 dB`( 5.5 MHz) |
|
Video SNR (weighted) |
≥ 56dB |
|
K coefficient |
≤ 4% |
|
Differential gain (P-P) |
≤ 8% |
|
Differential phase (P-P) |
≤ 8 degrees |
|
Non-linear brightness |
± 8% |
|
Chroma/Luma gain difference |
±5% |
|
Chroma/Luma delaying range |
±5% |
|
HDMI |
Supporting the 1.2 version standard |
Transmitting rate 4.95Gbps |
