DVB decoder1,optional for DVB-S/-S2/-T/-C, ISDB-T tuner inputs
2,VBI TELETEX,SUBTITILE support
3,NMS control support
DVB decoder
Outline
NDS391X Satellite Receiver with CI slot can decode transport stream from ASI, tuner or IP sources into audio and video signal. With the help of CAM module, it can decrypt the encrypted programs in the input TS. Apart from this function, it also can encapsulate the output TS into IP pocket and output in UDP protocol. User can watch the contents of the IP outputs from decoding software on computer. The professional IRD has full-range of output interface ports, such as HD-SDI, SD-SDI, HDMI, YPbPr, XLR, S/P DIF, etc., which can satisfy the professional user's needs.
Features
Factory optional for DVB-S/-S2/-T/-C, ISDB-T tuner inputs
MPEG-2 (MP/ML&MP/HL) and MPEG-4 Part 10 ( AVC high profile level 4.1) standards complaint and decoding
Various choice of I/O interfaces, including ASI input/output, CVBS output, YPbPr output, HDMI output, SD/HD output (embedded 2 pairs stereos audio), AES/EBU output, 10/100M TS over IP input/output ( optional)
Built-in re-multiplexer ( temporarily unavailable )
VBI TELETEX , SUBTITILE support
Caption support
10/100M Ethernet TS over IP I/O, UDP protocol
Unicast and multicast supportTwo DVB-CI slots, multiple programs decryption support
NMS control support
Specifications
DVB-CI module |
Descrambling procession |
Supporting European DVB-CSA |
Smart Card interface |
ISO7816 |
|
Interface Card separation |
PCMCIA |
|
ASI input |
BNC connector 1 route input; 2 routes output |
Input impedance 75 |
Maximum transmitting rate |
54Mbps |
|
ASI output |
BNC connector 1 route input; 2 routes output |
Output impedance 75 |
Maximum transmitting rate |
54Mbps |
|
Ethernet |
Connector |
RJ-45 |
Interface Type |
10/100 Base-T |
|
Protocols |
TS Over IP : UDP, NMS : UDP |
|
Video output |
CVBS×1 (BNC) |
576i-25 fps, 480i-29.94 fps |
YPbPr×1 (BNC) |
1080i-25 ,29.94fps 720p - 50 59.94fps |
|
SDI×1 (BNC) |
1080i-25 ,29.94fps;720p-50 59.94fps 576i-25 fps480i-29.94 fps |
|
HDMI×1 |
1080i-25 ,29.94fps720p-50 59.94fps 576i-25 fps;480i-29.94 fps |
|
Audio output |
Stereo unbalanced audio |
BNC interface |
Stereo balanced audio |
XLR interface |
|
Digital audio |
SPDIF |
|
General |
Dimensions ( L×W×H) |
482mm*360mm*44mm |
Approx weight |
3.2kg |
|
Power |
<20W(Max) |
|
Temperature range |
0~45∩ (Operation); -20∩~80∩ (Storage) |
