Specifications
1. 1 card maximum support 256 IP input and network de-jittering (250ms)2. 1 U with 3 cards
Overview
DX318 IP Mux-Scrambler is the latest multiplexing and scrambling device with high integration and powerful function. The modular design of this device makes each of its Slave cards as one device when operating. Besides, each Slave card can receive the UDP format TS through GE port. Furthermore, it supports up to 256 different IP address or port number input, integrates 8 multiplexers and 8 scramblers, which can output UDP format TS through the GE port. Additionally, 1U chassis can support maximum 3 modules (24 channels multiplexing and scrambling). In a conclusion, its high integration, high performance and low cost design makes this device widely used in the new generation of CATV broadcasting system.
Key features
l Module design, 1U device can support maximum three cards
l Totally supports DVB standards
l 1 card maximum support 256 IP input and network de-jittering (250ms)
l Total input bit-rate is 840Mbps per card
l Supports maximum 8 multiplexing and scrambler channels per card
l Supports PSI/SI inserting and editing
l Support 4 simulscrypt CA
l Support unicast and multi-cast IP Output
l Supports NMS management
Principle Chart:
