Asi to rf Modulator

Specifications

 Outline

DEXIN NDS3402E is a high-performance modulator developed according to DVB-S2 (EN302307) standard which is the standard of second generation of the European broadband satellite telecommunication. It is to convert the input ASI and IP signals alternatively into digital DVB-S/S2 RF output.

BISS scrambling mode is inserted to this DVB-S2 modulator, which helps to safely distribute your programs. It is easy to reach local and remote control with NMS software and LCD in the front panel.

With its high cost-effective design, DEXIN NDS3402E DVB-S2 modulator is wildly used for broadcasting, interactive services, news gathering and other broadband satellite applications.

Features

 Fully complying with DVB-S2 (EN302307) and DVB-S (EN300421) standard

 4 ASI inputs supporting hot backup

 Support IP signal input

 Constant temperature crystal oscillator, as high as 0.1ppm stability

 Support coupling 10Mhz clock output through RF output port

 Support BISS scrambling

 Support local and remote control

 Support SFN TS (with MIP or IIP) transmission

 Output frequency range: 950~2150MHz, 1KHz stepping

Principle Chart

Specifications
