Help CenterISDB-T H.264 IP Decoder
Related Products
Specifications
1. low cost , high quality2. CE,FCC certificate t
3. ISDB-T IRD
h.264 ip decoder
ISDB-T H.264 IP decoder
Input Frequency Range: |
170~230Mhz and 470~860Mhz |
Bandwidth: |
6MHz ( 6, 8MHz Optional) |
Input Level: |
0~-95dBm |
Constellations: |
QPSK,16QAM,64QAM |
Code rate |
1/2, 2/3, 3/4, 5/6, 7/8 |
Outline
NDS391X HD IRD with CI slot can decode transport stream from ASI, tuner or IP sources into audio and video signal. With the help of CAM module, it can decrypt the encrypted programs in the input TS. Apart from this function, it also can encapsulate the output TS into IP pocket and output in UDP protocol. User can watch the contents of the IP outputs from decoding software on computer. The professional IRD has full-range of output interface ports, such as HD-SDI, SD-SDI, HDMI, YPbPr, XLR, S/P DIF, etc., which can satisfy the professional user's needs.
Features
- Factory optional for DVB-S/-S2/-T/-C, ISDB-T tuner inputs
- MPEG-2 (MP@ML&MP@HL) and MPEG-4 Part 10 ( AVC high profile level 4.1) standards complaint and decoding
- Various choice of I/O interfaces, including ASI input/output, CVBS output, YPbPr output, HDMI output, SD/HD output (embedded 2 pairs stereos audio), AES/EBU output, 10/100M TS over IP input/output ( optional)
- Built-in re-multiplexer ( temporarily unavailable )
- VBI TELETEX , SUBTITILE support
- Caption support
- 10/100M Ethernet TS over IP I/O, UDP protocol
- Unicast and multicast support
- Two CI slots, multiple programs decryption support
- NMS control support
Series Specifications
DVB-CI module |
Descrambling procession |
Supporting European DVB-CSA |
Smart Card interface |
ISO7816 |
|
Interface Card separation |
PCMCIA |
|
ASI input |
BNC connector 1 route input; 2 routes output |
Input impedance 75Ω |
Maximum transmitting rate |
54Mbps |
|
ASI output |
BNC connector 1 route input; 2 routes output |
Output impedance 75Ω |
Maximum transmitting rate |
54Mbps |
|
Ethernet |
Connector |
RJ-45 |
Interface Type |
10/100 Base-T |
|
Protocols |
TS Over IP : UDP, NMS : UDP |
|
Video output |
CVBS×1 (BNC) |
576i/25 fps, 480i/29.94 fps |
YPbPr×1 (BNC) |
1080i/ 25 ,29.94fps 720p / 50 59.94fps |
|
SDI×1 (BNC) |
1080i/25 ,29.94fps;720p /50 59.94fps576i/25 fps480i/29.94 fps |
|
HDMI×1 |
1080i/25 ,29.94fps720p / 50 59.94fps 576i/25 fps;480i/29.94 fps |
|
Audio output |
Stereo unbalanced audio |
BNC interface |
Stereo balanced audio |
XLR interface |
|
Digital audio |
SPDIF |
|
General |
Dimensions ( L×W×H) |
482mm×360mm×44mm |
Approx weight |
3.2kg |
|
Power |
<20W(Max) |
|
Temperature range |
0~45°C (Operation); -20°C~80°C (Storage) |
