Specifications
ISDB-T BTS HD IRD1,ISDB-T tuner input
2,VBI TELETEX , SUBTITILE support
4,With CI slot
NDS398X ISDB-T BTS HD IRD
Product Overview
NDS398x Series HD IRD can decode TS signals from ASI, tuner (respectively support DVB-C/DVB-S/ DVB-T/DVB-S2/ISDB-T) or IP sources into audio and video signal. The device supports up to 1080i HD decoding and H.264 compressing standard, which is also compatible with MPEG-2. Moreover, it supports ISDB multiplexing function. After multiplexing the TS signals from tuner, ASI and IP sources according to the ISDB-T standard, then output ASI or IP (UDP) signals. Furthermore, it is equipped with CI decrypt descramble module, support multiple CA, LCD display in front panel and SNMP NMS.
Key features
l Support DVB-C/DVB-S/DVB-T/DVB-S2/ ISDB-T RF Input
l Support 1 RF,1 ASI, and 1 IP(100M) input
l Support 2 channels ASI output and 1 BTS over IP output
l Multiple Video and Audio format output
l Support H.264 and MPEG2 decoding
l LCD display and monitor window on the front panel
l Fully comply with ISDB-T/ISDB-Tb standard
l Support external 1PPS and 10Mhz input
l Support variable SI table editing
l Support NMS with SNMP,TCP/IP protocol
