Phaeton Solvent UD-32712X Inkjet Printer/Youtube Keyword: UD Printer

Phaeton Solvent UD-32712X Inkjet Printer/Youtube Keyword: UD Printer thumbnail-1
Phaeton Solvent UD-32712X Inkjet Printer/Youtube Keyword: UD Printer photo-1
US$ 100 - 1,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Galaxy Printek Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other
Place of Origin Guangdong, China
Brand Name Phaeton
Model Number UD-32712X
Usage Other
Automatic Grade Semi-Automatic
Dimensions(L*W*H) L4,850 x W1,070 x H1,585mm
Weight 710KG

Full aluminum platform / X, Y axis AC servo motors
Bearing rail, stable and long durability
Electric drive pinch rooler
Plastic Bar Pulling Material
Individual positive pressure cleaning

Model UD-32712X
Printhead SPT510-50PL
Number of printhead 12 Heads
Maximum print width 3,200mm
Print Speed (m2/h) Print mode Standard output(m2/h)
D 2 PASS 282
S 3 PASS 200
Q 4 PASS 153
HQ 4 PASS 120
C 6 PASS 105
BL 8 PASS 61
Ink     Type: ECO Solvent Ink/Solvent Ink
Color : 4 Color (C,M,Y,K)
Capacity: 5L per Main Tank of Each Color
Ink Supply System Low Ink Detector, Auto or Manual Ink Supply System
Media Width Maximum 3,300mm
Model UD-32712X
Media Type Vinyl, Window Flim, Polyester, Flex, Back-lit Film, etc.
Auto Media Feeding System Equipped (Max. Media Weight 80kg)
Auto Cleaning System Individual Positive Pressure Cleaning, Anti-clogged Flash Function & capping System
Pre-heating & Drying System Equipped
Clamp Equipped
Print Interface USB 2.0
Printhead Height 2 to 6 mm from Media
RIP Software Ultraprint, Maintop, Photoprint
Input Power AC 200V, 50Hz/60Hz
Operating Environment Humidity: 20-80% (Recommend 40-60%)
Temperature: 15-35°C
Machine Dimension / N.W L4,850 x W1,070 x H1,585mm / 710KG
Package Dimension / G.W L4,950 x W1,190 x H1,875mm / 1053KG
