Phaeton Solvent UD-3286E Inkjet Printer/Youtube Keyword: UD Printer

Phaeton Solvent UD-3286E Inkjet Printer/Youtube Keyword: UD Printer thumbnail-1
Phaeton Solvent UD-3286E Inkjet Printer/Youtube Keyword: UD Printer photo-1
US$ 100 - 1,000 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other
Brand Name:
Phaeton
Contact Supplier Request Quote Chat Now
Galaxy Printek Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Plate Type Other
Brand Name Phaeton
Model Number UD-3286E
Usage Other
Automatic Grade Semi-Automatic
Dimensions(L*W*H) L4766xW1160xH1350mm /724Kg



Output Chart

Printhead

SPT508GS

Number of prnthead

4/6 Heads

Output Quantity

Printing Mode

Outputs(m2/h)

2pass    Draft

91

3pass    Standard

                                   61

4pass    Quality





6pass   High Quality





46





31

8pass  Black lit

23













































*The above data is obtained when printing speed is set to high, value may vary in different computer*





Specification

Model

E

Max. printing width

3200mm

Max. media width

3300mm

Printhead Type

3286E

SPT508GS

6 heads

Ink

Type

Solvent or Eco-solvent

Color

(C,M,Y,K) or (C,M,Y,K,Lc,Lm)

Volume

2 liters main tank

Ink supply system

Ink level sensor. Auto-pumping

Media

Width

3300mm

Type

Banner, vinyl, polyester, etc

Feeding System

Single or double feeding bar. (Max weight 80kg)

Ph. Cleaning System

Individual color purging

Heating System

Back, middle, front, and extra heater.

Clamp

Equipped

Printhead Height

Adjustable distance from 2mm~6mm.

Input Voltage

AC220V,50Hz/60Hz

Printer Dimension/Weight

L4766xW1160xH1350mm/724Kg

Package Dimension/Weight

L4980xW1140xH1620mm/ 1011Kg
