Help CenterAuto Reverse With Safety Detection Automatic Gate Opener From Leading Supplier
Related Products
-
Light Profile Graded Automatic Gate Opener With Safety for Bulk BuyersUS$ 210 - 220MOQ: 1 Set -
Electricity Saving Reliable Automatic Gate Opener Available at Considerable PriceUS$ 210 - 220MOQ: 1 Set
-
Premium Material Latest Technology Made Electric Gate Opener for Bulk SaleUS$ 360 - 370MOQ: 1 Set
-
Long-Life High Quality Electric Gate Opener Available at Low PriceUS$ 360 - 370MOQ: 1 Set
-
High Strength and Durable Electric Gate Opener for Fast Speed at Considerable CostUS$ 360 - 370MOQ: 1 Set
Designed for a light-profile graded usage with motors integrated from the latest exclusive Italian Technology to
enhance the product’s performance. Its hard high-quality stainless steel and aluminium alloy, allows it to be
able to complete its modem: Safety, Reliability, Quality and Durability.
Quality
Using premium materials improvises the product into solid & long lasting
Reliable and Durability
Using premium materials extends the gate opener's durability and strongly holding the gate even if facing
aggressive shaking. Lifespan 8 years or more (Depends on Product usage)
Easy installation and maintenance
Brackets and installation are designed for position adjustment and motor release
Stainless steel brackets
Stainless steel and non-welding brackets are available
3-Speed Concept
Using "Slow-Fast-Slow" 3 speed concept control panel to ensure stable operation & prevent power leaking.
Product Details (Quick Details):
Type |
Gate Operators |
Place of Origin |
Malaysia |
Brand Name |
Nuova Luce Gate Operator |
Model Number |
KGA-NL |
Safety Detection |
Auto-reverse |
Drive |
Screw Driven Piston Type |
Max. Piston Speed |
2.2cm/sec |
Material |
High Strength Aluminium Alloy & Stainless Steel |
Operating Voltage |
DC 24V/ DC12V Swing Gate Opener |
Motor |
Rotary Planetary Reducer Gearbox |
Power Supply |
AC230V, 50Hz~60Hz |
Output Power |
80W per Driver |
Temperature |
0°C to + 80°C |
Max single-leaf length |
7 inch |
Gate Operator Profile
Gate Opener Size |
Length of the Arm actuator (Not Extend) |
Length of the Arm Actuator (Fully-Extend) |
Support Gate Width (Inch) |
Gate Types supporting (Swing / Folding Gate) |
KGA-NL |
60 CM +- |
91 CM +- |
14" or Below |
Both |
Technical Support :
Operating Voltage |
24VDC for Normal Speed 12VDC for Cushioning Speed |
Max. Output power |
80W Per Driver |
Max. Piston stroke |
31CM |
| Max. Piston speed | 2.2CM/SEC |
Operation Cycle |
14 SEC/90ºC (APPROX) |
Position Limit Device |
Electronic Fuzzy Logic |
Gearbox |
Rotary Planetary Reducer |
Safety Clutch |
Electronic Current Sensing |
Backup Battery |
12V 7AH |
Main Supply |
230VAC, 50HZ |
Electronic Controller |
Microcomputer Based |
Remote Controller |
UHF Digital PWM TYP |
Temperature |
0°C to + 80°C |
1 SET NUOVA LUCE Arm Type Swing Gate Operator completed with:-
- 2 Units Nuova Luce Arm Acutator c/w brackets and accessories
- 1 PC Nuova Luce Swing Control Board
- 1 Unit 12V 7AH Rechargeable Battery
- 1 Unit 10V-0-10V Transformer
- 1 Set 330Mhz 1+3 Remote Control
Delivery Details
3-5 working days for sample or small orders
25-30 working days for bulk orders
All delivery package will be arranged in form or according to your request
