DC3.3v 3a Switching Power Supply DC POWER SUPPLY
US$ 3.1 - 4.2
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
ueone
Model Number:
ms-10-3.3
Payment & Shipping
Payment Methods:
Port of Shipment:
ningbo/shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
12v 4a Led Power Supply 50w Switching Power Supply Quality GuaranteedUS$ 5.2 - 6.5MOQ: 1 Piece -
50w 5v Ac Dc Switch Power Supply 10a 50w Power SwitchingUS$ 5.2 - 6.5MOQ: 1 Piece
-
DC3.3V Constant Voltage Power Supply 3.3v 5a Switching Power SupplyUS$ 4.5 - 5.2MOQ: 1 Piece
-
12v 5amp Power Supply 12v 5a Switch Mode Power SupplyUS$ 5.2 - 6.5MOQ: 1 Piece
-
35w CE Aprroved 24v Small Size Switch Power SupplyUS$ 5 - 5.6MOQ: 1 Piece
Place of Origin
Zhejiang, China
Brand Name
ueone
Model Number
ms-10-3.3
Output Power
1 - 50W
Output Type
Single
Input Voltage
220V
Output Voltage
3.3v
Output Frequency
dc
Output Current
3a
Welcome,my friend! Glad to introduce 10w 3.3v 3a switching power supply CE factory price MS-10-3.3 . If you have any questions, please don't hesitate to ask me.
Features:
1. AC input range 86vac to 264vac 50/60HZ for the whole world
2. Protections: Short circuit / Overload / Over voltage
3. 100% full load burn-in test
4. Low cost, high reliability
5. 24 months warranty
6.Mini size
Product details
1.Product appearance pictures of 10w 3v 2a switching power supply CE factory price MS-10-3
| Model | MS-10-3.3 | MS-10 -7.5 | MS-10 -12 | MS-10 -15 | MS-10 -24 | MS-10 -48 |
| Specification | ||||||
| 7.5V | 12V | 15V | 24V | 48V | ||
| Output voltage range(Note:2) | ±2% | ±1% | ±1% | ±1% | ±1% | ±1% |
| Rated output current | 3A | 1.3A | 0.8A | 0.7A | 0.42A | 0.21A |
| Output current range | 0~3A | 0~1.3A | 0~0.8A | 0~0.7A | 0~0.42A | 0~2.5A |
| Wave and noise(Note:3) | 100mVp-p | 100mVp-p | 100mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
| Inlet stability(Note:4) | ±0.5% | ±0.5% | ±0.3% | ±0.3% | ±0.2% | ±0.2% |
| Load stability(Note:5) | ±0.5% | ±0.5% | ±0.3% | ±0.3% | ±0.2% | ±0.2% |
| DC output power | 10W | 10W | 10W | 10W | 10W | 120W |
| Efficiency | 76% | 78% | 80% | 81% | 83% | 84% |
| Adjustable range for DC voltage | 4.75-5.5V | 6.75-8.25V | 10.8-13.2V | 13.5-16.5V | 21.6-26.4V | 43.2-52.8V |
| AC input voltage range | 85~132VAC/170~264VAC selected by switch 47~63Hz,248~370VDC | |||||
| Input current | 2.6A/115V 1.3A/230V | |||||
| AC Inrush current | Cold-start current 15A/115V 30A/230V | |||||
| Leakage current | <1mA/240VAC | |||||
| Overload protection | 105 ~ 150% Protection type :pulsing hiccup shutdown Reset: auto recovery. | |||||
| Temperature coefficient | ±0.03%/°C(0~50°C) | |||||
| Setup, rise, hold up time | 200ms, 100ms, 30ms | |||||
| Vibration | 10~500Hz, 2G 10min,/1 cycle. Period for 60min,Each axes | |||||
| Withstand voltage | Input and output internal:1.5KvAC,Input and enclosure:l.5KvAC,Output and enclosure:0.5KvAC | |||||
| Isolation resistance | Input and output internal: Input and enclosure, Output and enclosure:500VDC/100MΩ | |||||
| Working temperature and humidity | -10°C~+60°C(Refer to output load derating curve),20%~90%RH | |||||
| Store temperature and humidity | -20°C~+85°C,10%~95%RH | |||||
| Overall dimension | 79X49X20mm (L*W*H) | |||||
| Weight | 0.2kg | |||||
| Safety standards | Meet UL1012 requirement(Not apply for the mark) | |||||
| EMC standards | Meet FCC PART 15J Conduction class B | |||||
| Note | 1. The parameter under the testing condition : 230vAC input ,rated load,25°C70% RH. Temperature. | |||||
| 2. Tolerance the setting tolerance, circuit stability and load stability.(Note:5). | ||||||
| 3. Wave test: adopting "A12"double wire for 20MHz, and 0.1 UF&47UF capacitor short-circuit for interrupting. | ||||||
| 4. Inlet voltage stability test : the lowest voltage will be up to the highest voltage when the circuit overload. | ||||||
| 5. Load stability test: The load is from 0% to 100%. | ||||||
