ccd night vision small rear view mirror reverse camera

Model

 CY2205M

CY2205P

Images sensors

Best Quality

Normal Quality

Resolution(TV Line)

480

420

Effective pixels

720*576 /720*480

580*540/580*492

Minimum illumination

0.5 lux

1 lux

IP rating

Ip68

Ip68

lens Angle(Deg.)

170°

170°

TV System

PAL/NTSC

PAL/NTSC

Power Supply(DCV)

DC12V±1V

DC12V±1V

Power

<1W

<1W

Electronic shutter

1/60(NTSC)1/50(PAL)1/10,000second

1/60(NTSC)1/50(PAL)1/10,000second

S/N Ratio

≥48dB

≥48dB

Video output

1.0vp-p.75ohm

1.0vp-p.75ohm

White Balance

Auto

Auto

AGC

Auto

Auto

Operating Temperature(Deg. C):

-20~+75(RH95% Max.)

-20~+75(RH95% Max.)

Storage Temperature(Deg. C):

-30~+85(RH95% Max.)

-30~+85(RH95% Max.)

Optional Function 1

Parking Line /Guide line

Parking Line /Guide line
