Excavator Bearings,bearing Manufactur All Types of Bearings 29434,
- Dalian Port
- T/T D/P D/A Credit Card PayPal
You May Like
-
Thrust Roller Bearing,bearing Manufactur Wind Turbines 29236,
-
Crusher Bearing Wind Generator 9069336,
-
Bearing Manufactur,large Bearing Hoverboard 29336,
-
Electric Motor Roller,excavator Bearing Zhauns Machine 9069436,
-
Industrial Bearing,excavator Bearing Industrial Rolling Pin 29436,
-
Slew Drive Bearing Insignia Pins 9069238,
Product Details
| Brand Name | WJJC or OEM | Bore Size | 100, 2000 | |
| Outside Diameter | 200, 2400 | Model Number | 29434, | |
| Precision Rating | P6,P5,P4,P2 | Seals Type | Open | |
| Number of Row | Double Row | Place of Origin | Liaoning, China |
Product Description
Axial spherical roller bearings and spherical roller bearings Likewise, the raceway surface is consistent with the bearing center axis as the center point of the spherical roller bearings such as spherical shape, and therefore, has a self-aligning feature for deflection and shaft concentricity less sensitive.
Application:
This kind of bearing is mainly used in oil drilling rig, made iron steel machinery, hydroelectric generators, vertical motors, marine propeller shaft, tower crane, extrusion machine.
We also offer other type bearing:
Deep Groove Ball Bearing
Cylindrical Roller Bearing
SinglRowCylindricalRollerBearing
DoubleRowCylindricalRollerBearing
FourRowCylindricalRollerBearing
Full Completed Cylindrical Roller Bearing
DoubleRowfullCompletedCylindricalRollerBearing
Spherical Roller Bearing with CA ,MB,CC,EE Constructure,Brass Cage,Steel Case,Black edge,Black Chamfer
Tapered Roller Bearing
SingRowTaperedrollerBearing
DoubleRowTaperedRollerBearing
FourRowTaperedRollerBearing
Deep Groove Ball Bearing
Angular Contact Ball Bearing
DoubleRowAngularContactBallBearing
FourPointAngularContactBallBearing
Spherical Roller Thrust Roller Bearing
ThrustSelf-AligningRollerBearing
SphericalthrustRollerBearing
Thrust Cylindrical Roller Bearing
DoubleThrustCylidnricaLRollerBearing
FourRowThrustCylindricalRollerBearing
Thrust Tapered Roller Bearing
DoubleRowThrustTaperedRollerBearing
SlewingRingBearing
FourPointBallSlewingRingBearingwithinnertooth,outertooth,withouttooth
CrossRollerslewingringbearing
PlainSphericalRollerBearing
| d (mm) | D (mm) | H(mm) | New | Old | Mass(kg) |
| 100 | 170 | 42 | 29320 | 9039320 | 3.91 |
| 100 | 210 | 67 | 9069420 | 10.5 | |
| 100 | 210 | 67 | 29420 | 9039420 | 10.5 |
| 110 | 190 | 48 | 9069322 | 5.46 | |
| 110 | 190 | 48 | 29322 | 9039322 | 6.94 |
| 110 | 230 | 73 | 9069422 | 12.8 | |
| 110 | 230 | 73 | 29422 | 9039422 | 18.1 |
| 120 | 210 | 54 | 9069324 | 6.88 | |
| 120 | 210 | 54 | 29324 | 9039324 | 7.3 |
| 120 | 250 | 78 | 9069424 | 19.5 | |
| 120 | 250 | 78 | 29424 | 9039424 | 17.1 |
| 130 | 225 | 58 | 9069326 | 8.26 | |
| 130 | 225 | 58 | 29326 | 9039326 | 8.48 |
| 130 | 270 | 85 | 9069426 | 23.0 | |
| 130 | 270 | 85 | 29426 | 9039426 | 28.3 |
| 140 | 240 | 60 | 29328 | 9039328 | 10.4 |
| 140 | 280 | 85 | 9069428 | 22.7 | |
| 140 | 280 | 85 | 29428 | 9039428 | 22.2 |
| 150 | 215 | 39 | 29230 | 9039230 | 4.6 |
| 150 | 250 | 60 | 9069330 | 10.2 | |
| 150 | 250 | 60 | 29330 | 9039330 | 11.5 |
| 150 | 300 | 90 | 9069430 | 27.3 | |
| 150 | 300 | 90 | 29430 | 9039430 | 27.9 |
| 160 | 225 | 39 | 29232 | 9039232 | 4.8 |
| 160 | 270 | 67 | 9069332 | 13.5 | |
| 160 | 270 | 67 | 29332 | 9039332 | 14.3 |
| 160 | 320 | 95 | 9069432 | 33.3 | |
| 160 | 320 | 95 | 29432 | 9039432 | 32.8 |
| 170 | 240 | 42 | 29234 | 9039234 | 6.0 |
| 170 | 280 | 67 | 29334 | 9039334 | 15.7 |
| 170 | 340 | 103 | 9069434 | 40.7 | |
| 170 | 340 | 103 | 29434 | 9039434 | 39.7 |
| 180 | 250 | 42 | 29236 | 9039236 | 7.05 |
| 180 | 300 | 73 | 9069336 | 18.3 | |
| 180 | 300 | 73 | 29336 | 9039336 | 19.9 |
| 180 | 360 | 109 | 9069436 | 42.3 | |
| 180 | 360 | 109 | 29436 | 9039436 | 64.2 |
| 190 | 270 | 48 | 9069238 | 8.0 | |
| 190 | 270 | 48 | 29238 | 9039238 | 8.7 |
| 190 | 320 | 78 | 29338 | 9039338 | 23.0 |
| 190 | 380 | 115 | 29438 | 9039438 | 75.6 |
| 200 | 280 | 48 | 29240 | 9039240 | 8.5 |
| 200 | 340 | 85 | 9069340 | 29.5 | |
| 200 | 340 | 85 | 29340 | 9039340 | 28.5 |
| 200 | 400 | 122 | 9069440 | 60.6 | |
| 200 | 400 | 122 | 29440 | 9039440 | 83.5 |
| 220 | 300 | 48 | 9069244 | 8.0 | |
| 220 | 300 | 48 | 29244 | 9039244 | 9.2 |
| 220 | 360 | 85 | 9069344 | 32.5 |
