WRP Single Scissor Electric Reach Stacker

Name: WRP Single Scissor Electric Reach Stacker
Brand: SINOLIFT
SKU: 132449537

WRP Single Scissor Electric Reach Stacker thumbnail-1

WRP Single Scissor Electric Reach Stacker photo-1

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Brand Name:

SINOLIFT

Model Number:

WRP

Contact Supplier Request Quote Chat Now

Shanghai Sinolift Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Brand Name SINOLIFT

Model Number WRP

Condition New

After-sales Service Provided Engineers available to service machinery overseas

WRP Single Scissor Electric Reach Stacker

1)Features

1.Italian Hydrapp Hydraulic system ensures high capacity, stable performance.

2.Safety shut-off valve and slow lowering function ensures operating safety.

3.Smart and compact design , high quality European mast.

4.Tilting up to 2 degree, down to 4 degree, perfectly meet need for cargo loading and unloading.

2)Specification Date

Model for Reach Stacker		WRP	WRP	WRP	WRP	WRP	WRP	WRP	WRP
Model for Reach Stacker		1020	1025	1030	1035	1040	1045	1050	1055
Power(battery,diesel,petrol,		electric
natural gas,manual)		electric
standing,Manner ofoperation:hand,		standing
pedestrian,seated,sorting-picker		standing
Load Capacity	Q(kg)	1000
Load Centre distance	c(mm)	500
Load Centre distance	x(mm)	375
Wheelbase	Y(mm)	1290					1380
Weight(including battery)	kg	1350	1385	1420	1450	1480	1850	1950	2050
Axle loading,laden front/rear	kg	810/570		830/590	880/600		1130/720	1210/740	1280/770
Axle unloading,unladen front/rear	kg	530/1870		540/1880	550/1930		1000/1850	1040/1910	1080/1970
Axle loading,unladen front/rear	kg	1000/1390		1020/1420	1040/1440		1230/1620	1280/1670	1330/1510
Tyres(rubber,highelastomer,		polyurethane
pneumatic,polyurethane		polyurethane
Wheel size drive side	mm	250x82
Wheel size load side	mm	150x82
wheel,number(x=drive wheel)		1+2
Track width(front)load side	b10(mm)	650					790
Track width(rear)load side	b11(mm)	980
Fork/mast tilting angle forward/backward	Grad	2.5
Lower mast height	h1(mm)	1615	1865	2115	2365	2615	2125	2385	2545
Free lift height	h2(mm)	-	-	-	-	-	1575	1700	1825
Lift height	h3(mm)	2000	2500	3000	3500	4000	4500	5000	5500
Extended mast height	h4(mm)	3070	3570	4070	4570	4920	5570	6070	6570
Overall length	l1(mm)	-	-	-	-	-	-	3095	-
Length between fork backrest and vehicle body	l2(mm)	1125
Overall width	b1Ib2(mm)	950/1100-1200
Fork size	s/e/l(mm)	40x100x950
Moveforward distance	l4(mm)	500
Ground clearance,center of wheelbase	m2(mm)	65
Aisle width forpallets 1000x1200	Ast(mm)	2714					2814
Aisle width for pallets 800x1200 lengthways	Ast(mm)	2800					2900
Swerve radius	Wa(mm)	2000					2050
Travel Speed Load/without load	Km/h	5/5.5					5/5.5
Lifting speed Load/without load	m/s	95/120
Lowering speed Load/without load	m/s	150/120
Max Gradeability Load/without load	%	5/12
Brakes		electriomagentic
Driving motor power	kW	0.9					1.2
Lifting motor	kW	3
Battery voltage,normal capacity K5	V/Ah	24/320
Battery weight	kg	275
Battery Dimension(L×W×H)	mm	812x270x535
Noise level at operator’s ears DIN12053	dB(A)	67

3)Photos

4)Workshop

5)Certificate

Shanghai Sinolift Equipment Co., Ltd is a production, design, manufacture, sales and service in one integrated production and trade enterprises. Main types of forklifts, material handling, storage and lifting products, also offer a variety of wire harnesses, TFT rule processing business, and produce a variety of OEM memory cards. Products are used in Germany and Japanese technology, all products passed "TUV", "CE", "GS" and "ISO9001" international quality system certification, the application of new technologies has unique.

6)Terms and Service

Lead time	3-4 weeks
Packing	Standard export fumigated wooden pallet, foam rubbers
Payment term	T/T payment in advance; L/C at sight
Lead term	FOB Shanghai or CFR/CIF
Warranty period	12 months
Shipping method	by sea or air; by express

7) Warranty Policy and Service Program

SINOLIFT give our customer warranty for each forklifts, pallet trucks (pallet jacks), stackers, table lifts , access work platform and drum handling equipments which remind us that we are always responsible for promotion our service.

Please check the warranty policy for the line of SINOLIFT material handling equipments from our sales department. Please note the warranty is for end user who purchase direct from SINOLIFT.

If your products from local distributor, please contact them. We provide full line after-sales service for our distributors. SINOLIFT believe local strategy is the best way for our distributors and local customers.

SINOLIFT offer all of handling equipments are reconditioned to our specifications, which come with a 12 months warranty on major components and 180 days on wearable items
