Factory Promotion CE/ROHS 18w 18w t8 led read tube
Voltage |
AC85 -240V |
LED type |
3528 |
LED QTY |
288PCS 3528 LED |
LED source color |
single color(W/R/G/B) |
Color Rendering Index |
above75 |
Total power |
18W |
Electrical efficiency |
0.88 |
Power factor |
0.92 |
Power unit |
built-in (Isolated) |
Material |
aluminum housing + PC cover |
Luminous Flux |
1750-1950LM |
Power efficiency |
96LM-106LM / W |
|
Color temperature (emitting color) |
Warm white: 2800-3500K |
Nature white: 4000-4500K | |
Daylight white: 5500-6500K | |
Cool white: 7000K+ | |
Beam angle |
120° |
Protection grade |
IP45 |
Ambient temperature |
-20 to 50°C |
Working temperature |
40-50°C |
Net weight |
0.3KG |
Lamp Dimension |
1200 x 26 mm |
Package Demission |
1270 x 240 x 240 mm (25PCS/CTN) |
Features for T8 led tube:
1.18W T8 LED tube light can be replacement of 40W or 45W traditional fluorescent lamp
2.80% energy saving than traditionall fluorescent tube
3. No buzzing noise, No RF interference
4. No flickering
5. Solid-state, high shock / vibration resistant
6. Eco-friendly. No UV, IR, mercury and other harmful materials
Jinshuo Illumination’s T8 LED Fluorescent Tube is an integrated product, the lightsource is combinated with the housing as one whole part, which is easy for installation, no need the exterior driver.
Applications for T8 led tube:
Replacement for conventional fluorescent tubes in
1. Hotels
2. Conference / Meeting rooms
3. Factories & Offices
4. Commercial Complexes
5. Residential / Institution Buildings
6. Schools, Colleges & Universities
Recommendation:
Item No |
Wattage |
LED(pcs) |
Dimension (mm) |
Luminous Flux(LM) |
Holder |
JS-T8-06 |
8W |
120 |
600x26 |
800 |
G13 |
JS-T8-06 |
10W |
144 |
600x26 |
960 |
G13 |
JS-T8-09 |
12w |
180 |
900x26 |
1150 |
G13 |
JS-T8-12 |
15W |
240 |
1200x26 |
1550 |
G13 |
JS-T8-12 |
18W |
288 |
1200x26 |
1800 |
G13 |
JS-T8-12 |
22W |
320 |
1200x26 |
2150 |
G13 |
JS-T8-12 |
25W |
360 |
1200x26 |
2400 |
G13 |
JS-T8-15 |
22W |
320 |
1500x26 |
2150 |
G13 |
JS-T8-24 |
36W |
576 |
2400x26 |
3400 |
G13 |
JS-T8-RGB |
Also can be made different color |
||||
JS-T9-Dim |
Now it can be dimmable |
||||
JS-T10-X |
T8 (26mm diameter) OR T10 (30mm diameter) is up to you |
||||
JS-T5-X |
T5 Series are very impression. |
||||
