Help CenterTank Truck Adaptor Valve/oil Discharge Coupler
Related Products
oil discharge coupler
can conveniently charging and discharging. For adopted the design of automatically floating lift valve.
when charging,if the lift valve is operating,the handle of oil discharge valve will always keep in closed condition
When discharging,the two opening position of handle can control the unloading flow.
The valve is light,its design and test are all fitting the API , It's compatible with API seal rapid joint.
Material:
Body: AL alloy
API valve head: hard AL
Lift valve: AL alloy
Seal: VITON / NBR
Operate shaft: SS
Feature:
Take the AL alloy casting structure, Anodic oxidation treatment,decrease the fluid line to increase the flow, SS material to improve the service life, grease nipple is easy to maintain ,user can check the liquid by the sight glass
Fit API1004, EN13083 and flange TTMA standard
Parameter :
Size |
4" |
Flow speed |
2500L/Min |
Working pressure |
0.6MPA |
Connect way |
Flange |
Operate way |
Manual |
Temperature |
-20 to 70 °C |
Media |
oil |
