wear resistant ceramic lining steel pipe elbow
- 5000 Meter / Meters per Month
- Shanghai port
- T/T
Product Details
Place of Origin: | Jiangsu, China | Type: | Ceramic Parts | Application: | Refractory |
Material: | Alumina Ceramic | Model Number: | Daika-A | Brand Name: | DAHUA |
Product Description
wear resistant ceramic lining steel pipe elbow
1. Regarding the ceramic steel pipe elbow
There is layer ceramic chip inside of steel pipe, so the most important advantages as follows:
a. Higher wear resistant and higher corrosion resistant
b. Higher heat resistant and higher pressureproof property
c. More longer service life than conventional pipes
2. Application Fields of ceramic steel pipe:
The ceramic lined pipe is widely used in steel plants, cement plants, power plants, coal mine and other heavy industry fields.
It's a very good solution to solve abrasion problem
3. Details of ceramic steel pipe:
Main Properties of Ceramic | |
Item | Index |
Content of Alumina | ≥92% |
Density | ≥3.5 g/cm3 |
Rockwell Hardness | ≥85 HRA |
Impact Strength | ≥850 Mpa |
Bending Strength | ≥290MPa |
Breaking Temper | ≥4.8MPa·m1/2 |
Coefficient of Linear Thermal Expansion | 20W/m.K |
product | Superior Quality High Wear Resisting Ceramic Steel Pipe |
wall thickness | 3-10mm |
Inner material | 92 % Alumina ceramics |
ceramic lining Thickness | 1 to 5mm |
Application | 1,Thermal power 2,steel Industry 3,mechanical industry 4,chemical Industry 5,Mine,coal industry 6,cement industry 7,Smelting industry |
Advantages | 1,lower cost than the cast iron pipe and alloy steel pipe. 2,low density,low weight and convenient installation 3,unique abrasion and impact resistant 4,excellent corrosion resistant 5,smooth inner wall |
Packing | Wooden cases |
Delivery Time | According to your requirement |
The Minimum quantity | 10m |
payment | L/C , T/T |
port | Shanghai |
availability | 5000m |
