x-ray baggage scanner AT-5030C for small size package security checking

PinPoint brand model

PD-5030A- Typical Steel penetration 32mm

X RAY baggage scanner | X-RAY luggage scanner

Designed to thwart the cleverest attempts at hiding weapons, drugs, stolen goods and other contraband, PD-5030a X-ray inspection systems are ideal for screening everything from small packages to oddly shaped items and palletized loads.

Excellent system for schools, hotels, convention centers and event-based security requirements

Tunnel Size: 500(W)*300(H)mm

Conveyor Speed: 0.22m/s

Conveyor Max Load: 150kg

Dose per Inspection: <2.9 μGy/h

Resolution: <0.101mm Metal Wire

Spatial resolution: Level: dia1.0mm, Vertical: dia1.3mm

Penetrate resolution: Dia 0.511mm

Penetration: 32mm Steel

Film Safety: Guarantee ISO1600 Film

X-ray Leakage: <0.05 μGy/h (at a distance of 5cm From external housing)

X-ray Generator

Generate direct: Upward

Generate angle: 80 degree

Anode Voltage: 140Kv

Anode power: 0.2 to 1.0mA

Cooling / Duty Cycle: Oil Cooling /100%

Image System

X-ray Sensor: L-Shaped Photodiode Array (multi-energetic), 12bit Deep

Monitor: 2 units, High Resolution Color, LCD Accord, 19 inch, operation desk(optional)

Image Processing: Edge enhancement, image strengthening, image lightening,, reducing darkening, image returning, image retrieval.

Image Grey Level: 4096

Image Max Resolution: 1024 * 1280pixel

Image Processing: 24bit for processing real time

Image storage: Storage 60000 pictures in real time

Zones & Zoom: 1-9 Image regions, 2,4,8,16 Times Enlarge, Whole screen continuous observation

Multi-energetic distinguish objects: organic objects in orange, inorganic objects in blue, mixture in green

High-energy/low energy: switch from high energy to low energy

Assist to detect drug and explosive powder

Installation Data

Operation temperature/Humidity: 0°C-45°C/20%-95%(non-condensing)

Storage Temperature/Humidity: -20°C-60°C/20%-95%(non-condensing)

Operation Power: 220VAC(±10%)50±3Hz

Power Consumption: 1.0 KW (max), 0.3KW(working)

Noise: <55db
