Mobile under vehicle inspection system, portable under car scanning system
Model: AT3000
Technical parameters
1 Vertical resolution of the image: 5000*2048 pixels
2 Check the width viewing angle: < 4 meters
3 Speed of vehicle: < 30km/h with ALPR(Automatic Licence Plate Recognition)
< 70km/h without ALPR(Automatic Licence Plate Recognition)
4 Effective Field of View(FOV):less than 170°
5 Weight capacity: <20T
6 Auxiliary light: 100W
7 Water-proof grade: Ip68
8 Scanning device weight: 24KG
9 Scanning device volume: 450mm×400mm×88mm
10 Communication interface: RS232/RS422
11 Operating Temperature: -10℃ to 55℃
12 Storage temperature: -40℃ to +75℃
13 Operating voltage: 110-240V AC, 50-60HZ
System Host
1 Brand: Grantech (UFO6377H-SP1-953)
2 CPU: Intel® Core(TM) 2 Duo CPU
P8600 2.4GHz or higher
3 Memory:2G( optional 4G)
4 Graphics:Inter(R) Gen 5.0 Integrated Graphics Engine
5 Hard Disk:SATA2 Hard Disk 500G
6 Dual LAN (At least one Intel Gigabit)
7 USB2.0 (Up to 4 pieces)
8 Monitor: 22inch LCD, resolution up to 1920*1080
Features
1 Automatic digital line scan camera, with high-resolution and clarity of the image.
2 The complete image of under vehicle scanning, without any omissions,
and the image is clear, complete, no distortion, can be clearly observed that
the object is not less than 2mm in diameter.
3 Preparation of inspection processes to meet a variety of on-site needs.
4 Multiple scene image monitoring, recording function.
5 Multi-language user interface design.
6 Strong scalability to easily achieve a variety of system linkage control.
7 (Optional)ALPR(Automatic Licence Plate Recognition)
(E.g.: anti-collision system, barrier, etc.).
8 (Optional) Multiple devices networked control functions
Specifications of Number Plate Reading System :
1 Pickup device: 1/4 inch CCD image sensor
2 System of signal: PAL
3 Horizontal Resolution: 600TV Line
4 Min Illumination:0.5 lux/f1.2
5 Optical Zoom:27x
6 Digital Zoom: 10x
7 Backlight compensation:Auto
8 AGC:Auto
9 White balance:Auto
10 Electronic Shutter: 1/50-1/100000 sec
11 S/N Ratio :48db
| Model | package Material | Package size | Weight | Volume |
| AT3000 |
Outside: wooden pallet inside: aluminum case |
880*850*690mm | 95kgs | 0.538cmb |
